Checklist
Perform these checks when you inspect the bearings:
Inspect the bearings for contamination and damage.
Note any lubricant condition and residue.
Inspect the ball bearings to see if they are loose, rough, or noisy when you rotate them.
Investigate any bearing damage to determine the cause. If the cause is not normal wear, correct
the issue before you return the pump to service.
Replacement bearings
Replacement bearings must be the same as, or equivalent to, those listed in this table.
NOTICE:
Thrust bearings must have machined bronze cages (retainers).
Table 3: Model 3610i-FRAME ball bearing fits
Bearing numbers are based on SKF designations.
Size
Radial Bearing Thrust Bear-
13D/15D
6309
22G
6312
33H
6313
43N
6318
53Q/55Q
6320
59Q
6224
Bearing housings
Perform these checks when you inspect the bearing housings:
Check that the bearing housings are very clean, with no burrs.
Remove all loose and foreign material.
Check the bearing housing bores against the values in the Ball bearing fits table.
3610 i-FRAME API 610 11th Ed/ISO 13709 2nd Ed, API Type BB1 Single-Stage, Axially-Split, Between-Bearing IOM
Bearing Housing
ing
Bore
mm | inch
100.00 | 3.9369
7309/BECBM
to
100.02 | 3.9379
130.00 | 5.1181
7312/BECBM
to
130.03 | 5.1191
140.00 | 5.5118
7313/BECBM
to
140.03 | 5.5128
190.01 | 7.4809
7318/BECBM
to
190.04 | 7.4820
215.02 | 8.652
7320/BECBM
to
215.04 | 8.4663
215.02 | 8.4652
7320/BECBM
to
215.04 | 8.4663
6.5 Preassembly inspections
Shaft Turn Radial
Shaft Turn Thrust
mm | inch
mm | inch
45.01 | 1.7722
45.01 | 1.7722
to
to
45.00 | 1.7718
45.00 | 1.7718
60.02 | 2.3628
60.02 | 2.3628
to
to
60.00 | 2.3623
60.00 | 2.3623
65.02 | 2.5597
65.02 | 2.5597
to
to
65.00 2.5592
65.00 | 2.5592
90.02 | 3.5440
90.02 | 3.5440
to
to
90.00 | 3.5434
90.00 | 3.5434
100.02 | 3.9377
100.02 | 3.9377
to
to
100.00 | 3.9371
100.00 | 3.371
120.02 |4.7251
100.02 | 3.9377
to
to
120.00 | 4.7245
100.00 | 3.9371
