Lubricating-Oil Requirements; Acceptable Oil For Lubricating Bearings; Replace The Oil Filter - ITT 3610 i-FRAME Manual

All frames in this table use a Watchdog Oiler, which has a capacity of 118 ml | 4 oz.
Size Radial Bearing
13D/15D 6309
22G 6312
33H 6213
43N 6318
53Q/55Q 6320
59Q 6224
Oil volume requirements for sleeve/tilt pad type bearings
The sleeve/tilt pad type bearing is a pressurized lubrication system where oil is flowed into the bearing.
The required system flow rate is dependent upon the bearing size and shaft speed.

5.5.2 Lubricating-oil requirements

Oil quality requirements
Use a high-quality turbine oil with rust and oxidation inhibitors with rated viscosity shown below at 38°C |
100°F.
Oil requirements based on temperature
For the majority of operating conditions, bearing temperatures run between 49°C | 120°F and 82°C | 180°F,
and you can use an oil of ISO viscosity grade 68 at 38°C | 100°F. If temperatures exceed 82°C | 180°F, refer to
the table for temperature requirements.
Temperature
Bearing temperatures exceed 82°C |
180°F
Pumped-fluid temperatures are ex-
treme

5.5.3 Acceptable oil for lubricating bearings

Acceptable lubricants
Brand
Exxon
Mobil
Sunoco
Royal Purple
*Acceptable oil brands are not limited to those listed above, brands listed are typically used by the OEM.

5.5.4 Replace the oil filter

1. Remove the oil filter (550A) and the oil filter plug (113Q) from the bearing frame (134). See
25: Oil filter and plug removal on page
3610 i-FRAME API 610 11th Ed/ISO 13709 2nd Ed, API Type BB1 Single-Stage, Axially-Split, Between-Bearing IOM
Drive End Bearing Housing
Oil Volume
ml ounces
n/a
n/a
2425 82
3076 104
3667 124
3667 124
Oil requirement
Use ISO viscosity grade 100. Bearing temperatures are generally about 11°C
| 20°F higher than bearing-housing outer surface temperatures.
Refer to the factory or a lubrication expert.
Ball/Ball
ISO VG 68
48.
Non Drive End Bearing Hous-
Thrust Bear-
ing
ml
7309/BECBM
7312/BECBM
7313/BECBM 4199
7318/BECBM 5826
7320/BECBM 7334
7320/BECBM 7334
Lubricant type
Sleeve/Ball
ISO VG 46
5.5 Bearing lubrication
ing Oil Volume
ounces
n/a
n/a
142
197
248
248
Sleeve/Tilt Pad
ISO VG 32
Figure
47
