4.4 Pump-to-driver alignment

4.4 Pump-to-driver alignment
Precautions
WARNING:
• Failure to disconnect and lock out driver power may result in serious physical injury or
death. Always disconnect and lock out power to the driver before performing any installa-
tion or maintenance tasks.
•
•
Alignment methods
Three common alignment methods are used:
• Dial indicator
• Reverse dial indicator
• Laser
Follow the instructions from the equipment manufacturer when you use the reverse dial indicator or laser
methods. Detailed instructions for using the dial indicator method are contained in this chapter.

4.4.1 Alignment checks

When to perform alignment checks
You must perform alignment checks under these circumstances:
• The process temperature changes.
• The piping changes.
• The pump has been serviced.
Types of alignment checks
Type of check
Initial alignment (cold alignment)
check
Final alignment (hot alignment) check After operation when the pump and the driver are at operating temperature.
Initial alignment (cold alignment) checks
When
Before you grout the baseplate
After you grout the baseplate
After you connect the piping
Final alignment (hot alignment) checks
When
After the first run
24 3610 i-FRAME API 610 11th Ed/ISO 13709 2nd Ed, API Type BB1 Single-Stage, Axially-Split, Between-Bearing IOM
Electrical connections must be made by certified electricians in compliance with all
international, national, state, and local rules.
Refer to driver/coupling/gear manufacturer's installation and operation manuals
(IOM) for specific instructions and recommendations.
When it is used
Prior to operation when the pump and the driver are at ambient temperature.
Why
This ensures that alignment can be accomplished.
This ensures that no changes have occurred during the grouting process.
This ensures that pipe strains have not altered the alignment.
Why
This ensures correct alignment when both the pump and the driver are at op-
erating temperature.
