6.6 Reassembly

Diameter of rotating member at clearance
50.00 to 64.99
65.00 to 79.99
80.00 to 89.99
90.00 to 99.99
100.00 to 114.99
115.00 to 124.99
125.00 to 149.99
150.00 to 174.99
175.00 to 199.99
200.00 to 224.99
225.00 to 249.99
250.00 to 274.99
275.00 to 299.99
300.00 to 324.99
325.00 to 349.99
350.00 to 374.99
375.00 to 399.99
400.00 to 424.99
425.00 to 449.99
450.00 to 474.99
475.00 to 499.99
500.00 to 524.99
525.00 to 549.99
550.00 to 574.99
575.00 to 599.99
600.00 to 624.99
625.00 to 649.99
For diameters greater than 649.99 mm | 25.999 in., the minimum diametrical clearances shall be
0.94 mm | 0.037 in. plus 1 mm for each additional 1 mm | 0.001 inch for each additional inch of diameter
or fraction thereof .
6.6 Reassembly

6.6.1 Assemble the rotating element

WARNING:
Lifting and handling heavy equipment poses a crush hazard. Use caution during lifting and
handling and wear appropriate Personal Protective Equipment (PPE, such as steel-toed shoes,
gloves, etc.) at all times. Seek assistance if necessary.
NOTICE:
Make sure that all parts and threads are clean and that you have followed all directions
under the Preassembly inspections section.
92
3610 i-FRAME API 610 11th Ed/ISO 13709 2nd Ed, API Type BB1 Single-Stage, Axially-Split, Between-Bearing IOM
2.000 to 2.4999
2.500 to 2.999
3.000 to 3.499
3.500 to 3.999
4.000 to 4.499
4.500 to 4.999
5.000 to 5.999
6.000 to 6.999
7.000 to 7.999
8.000 to 8.999
9.000 to 9.999
10.000 to 10.999
11.000 to 11.999
12.000 to 12.999
13.000 to 13.999
14.000 to 14.999
15.000 to 15.999
16.000 to 16.999
17.000 to 17.999
18.000 to 18.999
19.000 to 19.999
20.000 to 20.999
21.000 to 21.999
22.000 to 22.999
23.000 to 23.999
24.000 to 24.999
25.000 to 25.999
Minimum diametrical clearance
0.28
0.30
0.33
0.36
0.38
0.41
0.43
0.46
0.48
0.51
0.53
0.56
0.58
0.61
0.63
0.66
0.69
0.71
0.74
0.76
0.79
0.81
0.84
0.86
0.89
0.91
0.94
0.011
0.012
0.013
0.014
0.015
0.016
0.017
0.018
0.019
0.020
0.021
0.022
0.023
0.024
0.025
0.026
0.027
0.028
0.029
0.030
0.031
0.032
0.033
0.034
0.035
0.036
0.037
