• 1/2 in. NPT connection on the outboard side (551E)
Purge-oil mist lubrication provides intermittent oil mist in the bearing housing. This system uses the oil
sump in the housing, and requires the oil ring and the constant-level oiler.
Pure-oil mist lubrication provides constant oil mist in the bearing housing. This system does not use the
oil sump, oil ring, or constant-level oiler. The drain connections in the bearing housing are used as part of
the oil recirculation system.
1. On each the radial housing, replace the 1/4 in. NPT plug (133H) with an oil-mist fitting provided by
the oil-mist system manufacturer.
The 1/2 in. NPT connection (551E) remains plugged because it is not required in the oil-mist sys-
tem.
2. On the thrust housing, replace the 1/4 in. NPT plug (133H) with an oil-mist fitting. Replace the 1/2
in. NPT plug (551E) with a 1/2 in. to 1/4 in. bushing and insert an oil-mist fitting provided by the oil-
mist system manufacturer.
3. For pure-oil mist, connect the drain lines (408A) to the outlet connections. This is not required for
purge-oil mist.

5.5.7 Thrust Bearing Cooling Fan (Optional)

Precautions
WARNING:
• Running a pump without safety devices exposes operators to risk of serious personal in-
jury or death. Never operate a unit unless appropriate safety devices (guards, etc.) are
properly installed.
• Failure to disconnect and lock out driver power may result in serious physical injury or
death. Always disconnect and lock out power to the driver before performing any installa-
tion or maintenance tasks.
•
•
3610 i-FRAME API 610 11th Ed/ISO 13709 2nd Ed, API Type BB1 Single-Stage, Axially-Split, Between-Bearing IOM
Electrical connections must be made by certified electricians in compliance with all
international, national, state, and local rules.
Refer to driver/coupling/gear manufacturer's installation and operation manuals
(IOM) for specific instructions and recommendations.
