WARNING 66, Heat sink temperature low
The drive is too cold to operate. This warning is based on
the temperature sensor in the IGBT module. Increase the
ambient temperature of the unit. Also, a trickle amount of
current can be supplied to the drive whenever the motor
is stopped by setting parameter 2-00 DC Hold/Preheat
Current to 5% and parameter 1-80 Function at Stop.
ALARM 67, Option module configuration has changed
One or more options have either been added or removed
since the last power-down. Check that the configuration
change is intentional and reset the unit.
ALARM 68, Safe Stop activated
Safe Torque Off (STO) has been activated. To resume
normal operation, apply 24 V DC to terminal 37, then send
a reset signal (via bus, digital I/O, or by pressing [Reset]).
ALARM 69, Power card temperature
The temperature sensor on the power card is either too
hot or too cold.
Troubleshooting
•
Check that the ambient operating temperature is
within limits.
•
Check for clogged filters.
•
Check fan operation.
•
Check the power card.
ALARM 70, Illegal FC configuration
The control card and power card are incompatible. To
check compatibility, contact the Danfoss supplier with the
type code from the unit nameplate and the part numbers
of the cards.
WARNING/ALARM 71, PTC 1 Safe Stop
Safe Torque Off (STO) has been activated from the VLT
PTC Thermistor Card MCB 112 because the motor is too
warm. Once the motor cools and the digital input from the
MCB 112 is deactivated, normal operation can resume
when the MCB 112 applies 24 V DC to terminal 37 again.
When the motor is ready for normal operation, a reset
signal is sent (via serial communication, digital I/O, or by
pressing [Reset] on the LCP). If automatic restart is
enabled, the motor can start when the fault is cleared.
ALARM 72, Dangerous failure
STO with trip lock. An unexpected combination of STO
commands has occurred:
•
®
VLT PTC Thermistor Card MCB 112 enables
X44/10, but STO is not enabled.
•
MCB 112 is the only device using STO (specified
through selection [4] PTC 1 alarm or [5] PTC 1
warning in parameter 5-19 Terminal 37 Safe Stop),
STO is activated, and X44/10 is not activated.
WARNING 73, Safe Stop auto restart
Safe Torque Off (STO) activated. With automatic restart
enabled, the motor can start when the fault is cleared.
MG34U502
Operating Guide
ALARM 74, PTC Thermistor
Alarm related to VLT
PTC is not working.
ALARM 75, Illegal profile sel.
Do not write the parameter value while the motor is
running. Stop the motor before writing the MCO profile to
parameter 8-10 Control Word Profile.
WARNING 76, Power unit setup
The required number of power units does not match the
detected number of active power units. If the power card
connection is lost, the unit also triggers this warning.
Troubleshooting
•
•
WARNING 77, Reduced power mode
This alarm applies to only multi-drive systems. The system
is operating in reduced power mode (fewer than the
allowed number of drive modules). This warning is
generated on power cycle when the system is set to run
with fewer drive modules and remains on.
ALARM 78, Tracking error
The difference between setpoint value and actual value
exceeds the value in parameter 4-35 Tracking Error.
Troubleshooting
•
•
®
•
•
ALARM 79, Illegal power section configuration
The scaling card has an incorrect part number or is not
installed. Also, the MK101 connector on the power card
could not be installed.
ALARM 80, Drive initialised to default value
Parameter settings are initialized to default settings after a
manual reset. To clear the alarm, reset the unit.
ALARM 81, CSIV corrupt
CSIV file has syntax errors.
ALARM 82, CSIV parameter error
CSIV failed to initialize a parameter.
ALARM 83, Illegal option combination
The mounted options are incompatible.
ALARM 84, No safety option
The safety option was removed without applying a general
reset. Reconnect the safety option.
Danfoss A/S © 09/2018 All rights reserved.
®
PTC Thermistor Card MCB 112. The
Confirm that the spare part and its power card
are the correct part number.
Ensure that the 44-pin cables between the MDCIC
and power cards are mounted properly.
Disable the function or select an alarm/warning
in parameter 4-34 Tracking Error Function.
Investigate the mechanics around the load and
motor. Check feedback connections from motor
encoder to drive.
Select motor feedback function in
parameter 4-30 Motor Feedback Loss Function.
Adjust the tracking error band in
parameter 4-35 Tracking Error and
parameter 4-37 Tracking Error Ramping.
