Cable Specifications; Control Input/Output And Control Data - Danfoss VLT AutomationDrive FC 302 Operating Manual

Specifications
EMC standards, Emission
EMC standards, Immunity
1)
Energy efficiency class
1) Determined according to EN 50598-2 at:
•
Rated load.
•
90% rated frequency.
•
Switching frequency factory setting.
•
Switching pattern factory setting.

10.5 Cable Specifications

Cable lengths and cross-sections for control cables
Maximum motor cable length, shielded/armored
Maximum motor cable length, unshielded/unarmored
Maximum cross-section to motor, mains, load sharing, and brake
Maximum cross-section to control terminals, rigid wire
Maximum cross-section to control terminals, flexible cable
Maximum cross-section to control terminals, cable with enclosed core
Minimum cross-section to control terminals.
1) For power cables, see electrical data tables in chapter 10.1 Electrical Data.

10.6 Control Input/Output and Control Data

Digital inputs
Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic 0 PNP
Voltage level, logic 1 PNP
Voltage level, logic 0 NPN
Voltage level, logic 1 NPN
Maximum voltage on input
Input resistance, R
i
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
1) Terminals 27 and 29 can also be programmed as outputs.
Analog inputs
Number of analog inputs
Terminal number
Modes
Mode select
Voltage mode
Voltage level
Input resistance, R
i
Maximum voltage
Current mode
Current level
Input resistance, R
i
Maximum current
Resolution for analog inputs
Accuracy of analog inputs
MG34U502
Operating Guide
1)
Danfoss A/S © 09/2018 All rights reserved.
EN 61800-3
EN 61800-3
150 m (492 ft)
300 m (984 ft)
See chapter 10.1 Electrical Data
1.5 mm 2 /16 AWG (2x0.75 mm
2
1 mm /18 AWG
2
0.5 mm /20 AWG
2
0.25 mm /23 AWG
4 (6)
1) 1)
18, 19, 27 , 29 , 32, 33
PNP or NPN
0–24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
Approximately 4 kΩ
53, 54
Voltage or current
Switches A53 and A54
Switch A53/A54=(U)
-10 V to +10 V (scaleable)
Approximately 10 kΩ
±20 V
Switch A53/A54=(I)
0/4 to 20 mA (scaleable)
Approximately 200 Ω
30 mA
10 bit (+ sign)
Maximum error 0.5% of full scale
IE2
2 )
10 10
2
103
