Electrical Installation
5.8.6 D6h Terminal Dimensions
1
458 (18.0)
2
153 (6.0)
123 (4.8)
0.0
1
Mains terminals
2
Ground terminals
3
TB6 terminal block for contactor
Illustration 5.19 D6h Terminal Dimensions with Contactor Option (Front View)
MG34U502
Operating Guide
4
Brake terminals
5
Motor terminals
–
–
Danfoss A/S © 09/2018 All rights reserved.
3
4
227 (8.9)
195 (7.7)
5
96 (3.8)
5
5
47
