Electrical Installation
1
225 (8.9)
2
0.0
1
Mains terminals
2
Ground terminals
3
TB6 terminal block for contactor
Illustration 5.21 D6h Terminal Dimensions with Contactor and Disconnect Options (Front View)
MG34U502
Operating Guide
4
Brake terminals
5
Motor terminals
–
–
