Electrical Installation
727 (28.6)
1
623 (24.5)
517 (20.4)
511 (20.1)
0.0
1
Mains terminals
2
Brake terminals
Illustration 5.17 D5h Terminal Dimensions with Brake Option (Front View)
MG34U502
Operating Guide
3
Motor terminals
4
Ground terminals
