Electrical Installation
5.8.5 D5h Terminal Dimensions
1
221 (8.7)
2
148 (5.8)
118 (4.6)
0.0
1
Mains terminals
2
Ground terminals
Illustration 5.15 D5h Terminal Dimensions with Disconnect Option (Front View)
MG34U502
Operating Guide
3
Brake terminals
4
Motor terminals
Danfoss A/S © 09/2018 All rights reserved.
3
227 (9.0)
196 (7.7)
4
90 (3.6)
5
5
43
