Electrical Installation
5.8.3 D3h Terminal Dimensions
1
188 (7.4)
83 (3.3)
0.0
1
Mains terminals
2
Brake terminals
Illustration 5.11 D3h Terminal Dimensions (Front View)
MG34U502
Operating Guide
3
Motor terminals
4
Ground terminals
Danfoss A/S © 09/2018 All rights reserved.
292 (11.5)
2
5
5
