FX-4000
Intelligent Fire Detection and Voice Evacuation System
LT-894MP Rev 1
Installation and Operation Manual
Sep 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FleXNet FX-4000 and is the answer not in the manual?

Questions and answers

Steven Weinrieb
February 4, 2025

The building is a new 16 floor residential high rise. The building is an infill and shares common zones in a shared garage. It is a single stage system On the panel, Each above grade floor has a page button. It also has individual zone buttons laved evacuation. I was told by the tech that buttons only work when the alarm is not activated. Depressing a zone evacuation will cause the alarm to sound only on that floor. is that correct? How is this reset. Where in the manual can i find the operation of this feature. thanks

0

Subscribe to Our Youtube Channel

Related Manuals for Mircom FleXNet FX-4000

Summary of Contents for Mircom FleXNet FX-4000

  • Page 1 FX-4000 Intelligent Fire Detection and Voice Evacuation System LT-894MP Rev 1 Installation and Operation Manual Sep 2021...

  • Page 2: Table Of Contents

    Table of Contents Introduction System Components Mechanical Installation and Dimensions Display and Adder Modules Mounting Locations Module Settings Field Wiring System Checkout Indicators, Controls, and Operation Configuration 10.0 Typical FleX-Net™ System Layouts with Audio 11.0 System Components for the Integrated Fire/Audio Cabinet 12.0 FleX-Net™...
  • Page 3 30.0 Paging Operation 31.0 TNC-5000 Telephone Network Controller Module 32.0 QMT-5302NV Vertical Master Telephone 33.0 QMT-5302N Master Firefighters’ Telephone 34.0 QMT-5302N Connections 35.0 QAZT-5348DS and QAZT-5302DS Firefighters’ Telephone Selector Panel 36.0 Telephone Operation 37.0 Appendix A: Specifications 38.0 Appendix B: Power Supply and Battery Calculations 39.0 Appendix C: DIP Switch Settings 40.0...

  • Page 4: Introduction

    About the FleX-Net™ FX-4000 Intelligent Fire Detection and Voice Evacuation System Mircom’s FleX-Net™ FX-4000 Intelligent Fire Detection and Voice Evacuation System offers modular components for network systems providing a wide variety of applications. Designed for peer to peer network communications, using industrial standard ARCnet protocol. FleX- Net™...
  • Page 5 Walk Test. • Outputs for 4 Wire resettable Smoke Power Supply, Auxiliary Power Supply, and an interface to the Mircom RTI-1 Remote Trouble Indicator. • RS-485 Interface for Remote Annunciators. Remote Annunciators do not occupy a node on the network. Up to seven annunciators can be connected per node.
  • Page 6 Overall Audio Features: • Supervises signal circuits while in use. • Control of fire management operations (e.g. all-call paging and total evacuation signalling). • Indication of all required fault conditions. • Microprocessor-based operations with hardware and software watchdog timer to ensure reliable system operation.

  • Page 9: System Components

    System Components Chassis Types Model Description 12 Amp Main Chassis. This main chassis provides four Class A or B NACs (1.7 Amp each), and a 12 ampere power supply which charges 17-65 AH batteries. The FX-4003-12N supports the FNC-2000 Network Controller Module and 2 adder modules over the main board plus additional space in the chassis for 2 annunciator or programmable modules.
  • Page 10 Model Description 12 Amp Large Main Chassis. This large main chassis provides four Class A or B NACs (1.7 Amp each), and a 12 ampere power supply which charges 17-65 AH batteries. The FX-4009-12N supports the FNC-2000 Network Controller Module and 2 adder modules over the main board plus additional space in the chassis for 6 adder boards and 3 annunciator or FX-4009-12N...
  • Page 11 Model Description Telephone Network Controller module. The TNC- 5000 Telephone Network Controller module is mounted over the ANC-4000 Audio Network Controller module and both are mounted on a TNC-5000 metal plate and then the plate is mounted in a BB-5008 or BB-5014 backbox in positions marked 4 to 9 inclusive.
  • Page 12 Model Description SGM-1004A Four NAC circuit Module RM-1008A Eight Relay Circuit Module PR-300 Polarity Reversal and City Tie Module UDACT-300A Digital Communicator/Dialer Module Display Modules Model Description 4 line by 20 character display which can be mounted into backboxes BBX- DSPL-420DS 1072ADS(ARDS), BB-5008(R), BB-5014 and the BBX-FXMNS Backbox.
  • Page 13 Programmable Modules Model Description IPS-4848DS 48 Programmable Input Switches Module IPS-2424DS 24 Programmable Input Switches Module Fan Damper Module with white LEDs for AUTO switch position indication. FDX-008W provides FDX-008W switch operation of 8 fan damper zones and the FDX-008WKI provides switch operation of 7 FDX-008WKI fan damper zones and one keyswitch operation of the 8th fan damper zone.
  • Page 14 Model Description Network Master Telephone Control Panel QMT-5302NV (Vertical Mount) mounts within the BBX- FXMNS enclosure. QAZT-5348DS 48 Zone Paging and Telephone Selector Panel QAZT-5302DS 24 Zone Paging and Telephone Selector Panel Booster Power Supply Model Description Addressable Booster Power Supply mounts to backboxes BB-5014 and BBX-FXMNS.
  • Page 15 Enclosures Model Description BBX-1024DS white door black backox Enclosure 27.5”H x 16.5”W x 5.5”D (add suffix “R” for red door/black backbox) BBX-1024XT white door black backbox Enclosure 35.5”H x 16.5”W x 5.5”D (add suffix “R” for red door/blackbox) BBX-1072ADS white door black backbox (or Enclosure 34”H x 26.5”W x 7.7”D BBX-1072ARDS for red door black backbox) BB-5008 black door and backbox...
  • Page 16 Model Description Model RAM-1032TZDS Main Chassis Remote Annunciator with 16 Bi-coloured LEDs and 32 trouble LEDs. Model RAM- RAM-1032TZDS 1032TZDS-CC is the same as the RAM-1032TZDS, except it has RAM-1032TZDS-CC conformal coating and is to be used in a BB-1001WP(R)A or BB- 1002WP(R)A weather protected box.
  • Page 17 FX-LOC Enclosure includes backbox, inner The FX-LOC(R) Local Operating Console along door and outer white door. with the Mircom FleX-Net™ Network Fire Alarm FX-LOCR, the R suffix system facilitates a Mass Notification System. represents a red door. The FX-LOC(R) provides critical emergency (as...

  • Page 18: Mechanical Installation And Dimensions

    Mechanical Installation and Dimensions Install the enclosure as shown for the BBX-1024DS installation information is in Figure 1. For the BBX-1072ADS see Figure 2. Figure 3 demonstrates the BB-5008 backbox installation. Figure 1 .BX-1024DS Flush and Surface Enclosure Installation and Dimensions BBX-1024DS BACKBOX AND DOOR 5 3/4”...
  • Page 19 Figure 2 BBX-1072ADS Flush and Surface Installation and Dimensions Material: Cold rolled steel, 16GA (0.059”)thick for backbox, 14GA (0.075”) thick for door Finish: Painted except for hinges...
  • Page 20 Figure 3 BB-5008 Enclosure Installation Instructions and Dimensions Material: Cold rolled steel BB-5008 Backbox Backbox 16GA (0.059”) thick for backbox 14GA (0.075”) thick for door Finish: Painted except for hinges Backbox with DOX-5008M Door DOX-5008M Metal Door...
  • Page 21 BBX-1024XT(R) Mechanical Installation The model FX-4003-12NXT is an expanded version of the FX-4003-12N chassis. The FX- 4003-12NXT mounts into the BBX-1024XT(white enclosure) and the BBX-1024XTR(red enclosure) 14.76” wide by 35.8” long by 5.45” Dimensions 16GA (0.059”) thick for backbox Cold Rolled Steel 14GA (0.075”) thick for door Cold Rolled Steel Painted except for hinges...
  • Page 22 General Chassis Installation 1. Group the incoming wires through the top of the enclosure to prepare it for wiring the modules. Do not run the wires in-between the modules since it could cause a short circuit. 2. Use a wire tie to group wires for easy identification and neatness. 3.
  • Page 23 Figure 5 Installation Instructions and Dimensions for BB-5014 BB-5014 Backbox Backbox Material: Cold rolled steel 16GA (0.059”) thick for backbox 14GA (0.075”) thick for door Finish: Painted except for hinges Backbox with DOX-5014M Door DOX-5014M Metal Door...
  • Page 24 Module Mounting Locations The FX-4003-12N or FX-4017-12N Main Chassis come pre-assembled with a main fire alarm board. Install the adder modules of different types as shown in the following diagrams. Notes: For many adder modules to enable communication from the main module to all of the adder modules, it is necessary to add a continuity jumper on the last adder module in a chain (see the appropriate module settings section to verify the location of the continuity jumper on a particular circuit adder module).
  • Page 25 Figure 7 Module Mounting Locations View #2 Provision for PR-300 or Main Chassis UDACT-300A FX-40XX-12N FNC-2000 in position 2 and other Adder Module in position 1 MD-579 MD-575 Long Ribbon Cable MD-579 Short Power Cable MD-580 Long Power Cable FNC-2000 Fire Network Controller Module This module is required in the main lobby and one per node.

  • Page 26: Display And Adder Modules Mounting Locations

    Display and Adder Modules Mounting Locations FX-4003-12N Compact Main Chassis Mounts in the BBX-1024DS Enclosure and supports three adder modules. Interior View Inside Backbox View Slot 3 is reserved for PR-300 or UDACT-300A. If not required, this slot can be used to mount any of the adder modules.
  • Page 27 FX-4017-12N Mid-size Main Chassis Mounts in the BBX-1072ARDS Enclosure, and supports three display modules and 17 adder modules. Interior View Inside Backbox View FX-2000 Main Board Slot 3 is reserved for PR-300 or UDACT- 300A. If not required, this slot can be used to mount any of the adder modules.
  • Page 28 ECX-0012 Expander Chassis for FX-4009-12N Mounts and occupies two display positions in BB-5008 or BB-5014 Enclosures, and supports two display and 12 adder modules. Interior View Inside Backbox View Cutout to mount Cutout to mount display module display module Network Controller Modules The FNC-2000 Fire Network Controller module is mounted in position 2 over the FX-4000N main board.
  • Page 29 4.6.1 Adder Modules Each adder module occupies one module slot and mounts inside the following chassis: • FX-4003-12N Compact Main Chassis • FX-4003-12NXT Mid-size Main Chassis • FX-4017-12N Mid-size Main Chassis • FX-4009-12N Large Main Chassis and ECX-0012 Expander Chassis for FX-4009-12N ALCN-960MISO DM-1008A SGM-1004A...
  • Page 30 4.6.2 Display Modules Each display module occupies one display position and mounts to the display cutouts on the following chassis: • FX-4003-12N Compact Main Chassis • FX-4003-12NXT Mid-size Main Chassis • FX-4017-12N Mid-size Main Chassis • FX-4009-12N Large Main Chassis •...

  • Page 31: Module Settings

    Module Settings Main Fire Alarm Module (MD-871A “N” Version Main Chassis) This main board has one addressable loop and network capability. Jumper is removed if a PR-300 or UDACT-300A is installed. Jumpers are Factory Set and should not be changed. JW2,JW4 Normally un-installed, add jumper to silence on-board buzzer.
  • Page 32 TO CONFIGURE THE FIRE ALARM PANEL USE THE RS-485 CONNECTOR P4 OF THE LAST ADDER LOOP CONTROLLER MODULE INSTALLED OR IF NOT PRESENT, P3 ON THE FleX-Net™ MAIN FIRE ALARM MODULE. Figure 8 Main Fire Alarm Module (MD-871A “N” Version Main Chassis) FIELD WIRING TERMINALS MAIN FIRE ALARM BOARD P2 P1...
  • Page 33 DSPL-420DS Main Display Module The DSPL-420DS mounts into backboxes BBX-1072ARDS, BB-5008(R), BB-5014(R) and BBX-FXMNS. Figure 9 DSPL-420DS Main Display Module BLDG GENERAL QUEUE QUEUE QUEUE ALARM QUEUE GENERAL LAMP SYSTEM FIRE SIGNAL ALARM TEST DRILL RESET SILENCE CANCEL P1: Cable connects to P14 of the FX-4000N main fire alarm board (Figure 8). P2: Connection to P1 of any adder display module if used.
  • Page 34 DSPL-2440 Graphical Main Display Module The DSPL-2440 is a separate item. It can be mounted into backboxes BBX-1072ARDS, BB- 5008(R), BB-5014(R) and BBX-FXMNS. Figure 10 DSPL-2440 Graphical Main Display Module BLDG TROUBLE SUPV TROUBLE QUEUE QUEUE QUEUE QUEUE P1: Cable connects to P14 of the FX-4000N main fire alarm board (Figure 8). P2: Connection to P1 of any adder display module if used.
  • Page 35 FNC-2000 Fire Network Controller Module An FNC-2000 Fire Network Controller module is required in each fire alarm node in the system. The FNC-2000 also provides a connection for an optional FOM-2000-UM Fiber Optics Module. Figure 11 FNC-2000 Fire Network Controller Module This cable connects to P19 on the...
  • Page 36 FOM-2000-UM Multi Mode Fiber Optic Network Module One of these modules is required at each panel where fiber optics will be used between them. The FOM-2000-UM will be mounted over the FNC-2000 Network board (over the field wiring terminals) with two #6 Phillips screws and two Hex spacers. Figure 12 FOM-2000-UM Multi Mode Fiber Optic Network Module Bay for optical module Bay for optical module...
  • Page 37 Table 3 RAX-1048TZDS Zone Display Module Cable Function Connector Function P1 Cable connects to P2 of previous display module. P2 Cable connects to P1 of next display module Note: The zone display module comes with laser printer-compatible slide-in paper labels for zone labelling.
  • Page 38 Table 4 IPS-4848DS Programmable Input Switches Module Cable Function Connector Function P1 Permanently connected cable connects to P2 or P4 of previous display module. P4 Cable connects to P1 of next display module Note: The IPS-4848DS module comes with laser printer-compatible slide-in paper labels for zone labelling.
  • Page 39 Fan Damper Control Display Module (FDX-008W(KI)) There are two models of the Fan Damper Control Display modules available. The FDX-008W provides switch control and LED indication of 8 fan damper zones. The FDX-008WKI provides switch control of 7 fan damper zones with the eighth zone activated by keyswitch. LED indication is provided for all 8 fan damper zones on the FDX-008WKI.
  • Page 40 AUTO LED shows steady for switch in AUTO position. ON LED shows steady for all outputs operating and confirmed. OFF LED shows steady for all outputs NOT operating and confirmed. TRBL LED shows steady for one or more outputs NOT operating and confirmed. Note: A bypass function always has priority, so that if a circuit is bypassed by moving the switch manually or by loop bypass (FX-4000N Fire Alarm Panel), no other action will operate this switch other than again moving the switch manually or by un-bypassing the...
  • Page 41 Figure 18 FDX-008WKI Fan Damper Control Display Module TERMINALS AT TS1 ARE WIRED TO A KEYSWITCH. NOTE: IF FAN DAMPER MODULE IS MOUNTED TO THE DOOR USE TERMINALS LOCATED AT THE BACK OF THIS BOARD, BEHIND TS1. OFF AUTO ON TROUBLE OFF AUTO ON TROUBLE...
  • Page 42 5.10 Hardwire Detection Adder Module (DM-1008A) Figure 19 Hardwire Detection Adder Module (DM-1008A) Power connector to P8 of Data cable to P6 or P5 of main fire alarm module, main fire alarm module or to or to P2 of hardwire loop P13 or P12 of hardwire loop controller module, or controller module, or to...
  • Page 43 5.11 Hardwire Signal Adder Module (SGM-1008A) Figure 20 Hardwire Signal Adder Module (SGM-1004A) ZONE 4 1 2 3 Power connector to P8 of Data cable to P6 or P5 of main fire alarm module, or main fire alarm module to P2 of loop controller or to P13 or P12 of loop ZONE 3 module, or to previous...
  • Page 44 5.11.4 Isolator Mode Jumpers for the Isolator Mode JW2: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 1. JW3: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 2. JW4: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 3.
  • Page 45 5.13 Polarity Reversal and City Tie Module (Model PR-300) Figure 22 Polarity reversal and city tie module Mounting hole for #6-32 screws Mounting hole for #6-32 screws The following hardware configuration must be performed before installing the PR-300. Table 6 PR-300 Connectors and Jumper Settings Cable connects to P4 on the FX-4000N Main Fire Alarm Board Not used.
  • Page 46 5.14 UDACT-300A Digital Alarm Communicator Module There are two jumpers on the UDACT-300A which are used for operation/configuration purposes. Jumper JW1 is used to reset the default passcode. Jumper JW2 is required for configuring (which can be done using the FX-4000N Configurator Software) the UDACT-300A. Refer to Figure below for location of jumpers, cable connections, pushbutton and LEDs.
  • Page 47 Table 7 UDACT-300A Cable Connectors and Miscellaneous Cable Connector Function Ribbon Cable for connecting to P4 of FX-4000N main fire alarm module or to P2 header on the PR-300 if used. RS-232C/RS-485 Connection for computer configuration. Connector for CFG-300 Configuration Tool Press and hold this button to test all the UDACT-300A LEDs Lamp Test button This potentiometer is for adjustment of the CFG-300 LCD contrast.
  • Page 48 Note: This module cannot be installed if a city tie module is used. See the UDACT-300A Installation and Operation Manual LT-888 for more information. 5.15 ALCN-960MISO Quad Loop Adder Module with ALCN-960D Daughter Board The Quad Loop Adder module provides two SLC loops, plus an additional two SLC loops as part of the daughter board ALCN-960D which is mounted over the ALCN-960MISO.
  • Page 49 Figure 24 ALCN-960MISO Quad Loop Adder Module SHIELD LOOP 1 LOOP 2 NOT USED Important: The top two mounting holes must be ALARM OUT electrically connected to COM (-) the chassis using metal RS-485 USB PORT Loop 1 Loop 2 RS-485 heartbeat Active LED Active LED...
  • Page 50 5.16 ALCN-4792MISO Quad Loop Adder Module with ALCN-792D Daughter Board The Quad Loop Adder module provides two SLC loops plus an additional two SLC loops as part of the daughter board ALCN-792D which is mounted over the ALCN-4792MISO. The Quad Loop Adder module may be mounted over the main chassis of the fire alarm panel. Refer to the Display and Adder Modules section for mounting applications.
  • Page 51 Figure 26 ALCN-4792MISO Loop Adder Board SHIELD LOOP 1 LOOP 2 NOT USED ALARM OUT COM (-) RS-485 Green flashing USB PORT Loop 1 Loop 2 RS-485 heartbeat (Factory use only) Active LED Active LED RS-485 Daughter Board Four shaded Connector mounting holes are JW1 - leave open...
  • Page 52 The ALCN-792D Daughter Board provides an additional two addressable loops when connected to the ALCN-4792MISO Quad Loop Adder Board. This daughter board is mounted over the ALCN-4792MISO. Wire the two addressable loops on the ALCN-792D Daughter Board in the same manner the ALCN-4792MISO addressable loops are wired. Figure 27 ALCN-792D Daughter Board Four mounting holes (mount to ALCN-4792MISO board with screws...

  • Page 53: Field Wiring

    Field Wiring Main Fire Alarm Board Terminal Connections Wire devices to terminals as shown in Figure 28 below. Refer to Appendix A for specifications and to LT-1023 for compatible devices. Do not exceed power supply ratings: Main Chassis: FX-4003-12N, FX-4003-12NXT, FX- 4009-12N or FX-4017-12N: total current for NACs is 10A max.
  • Page 54 INTERNAL POWER-LIMITED, 22V DC, 400 mA MAX ADDRESSES Maximum Loop Resistance 40 ohms FOR FIRST 8 CARDS AND CONNECTION TO MIRCOM RTI THIS SLC LOOP IS NOT AVAILABLE SECOND 8 REMOTE TROUBLE INDICATOR WHEN USING AN ALCN-960MISO CARDS (SEE RTI INSTALLATION...
  • Page 55 SLC Loop Wiring Figure 30 SLC Loop Terminal Connections - Class B TWIS TE D P AIR WIR E Conventional Heat Sensors and Manual Pull Stations FX-4000 MAIN FIRE ALARM BOARD 2 P air TWO WIR E S ANAL OG LOOP THIS LOOP IS NOT AVAILABLE CONNECTIONS...
  • Page 56 Figure 31 SLC Loop Terminal Connections - Class X TWIS TE D P AIR WIR E ADDRESSABLE SMOKE DE TEC TOR WITH ISOLA TOR BASE FX-4000 MAIN FIRE ALARM BOARD TWIS TE D P AIR WIR E TWIS TE D P AIR WIR E ADDRESSAB THERM AL SENSOR...
  • Page 57 Figure 32 SLC Loop Terminal Connections - Class A ADDRESSABLE THERM AL SENSOR TWIS TE D P AIR WIR E FX-4000 MAIN FIRE ALARM BOARD TWIS TE D P AIR WIR E ADDRESSABLE SMOKE DE TEC TORS Conventional 4-Wire Smoke Detectors, Heat Sensors and Manual Pull Stations THIS LOOP IS NOT AVAILABLE...
  • Page 58 Figure 33 Quad SLC Loop Terminal Connections - Class B ALCN-960MISO or ALCN-4792MISO QUAD LOOP ADDER MODULE TWISTED P AIR WIRE Conventional Heat Sensors ANAL OG and Manual Pull Stations LOOP 1 TWISTED PAIR WIRE 2 Pair ANAL OG LOOP 2 TWO WIRES FX-4000 LEGEND...
  • Page 59 Figure 34 Quad SLC Loop Adder Module Terminal Connections - Class X ALCN-960 MISO or ALCN-4792MISO QUAD LOOP ADDER MODULE TWISTED PAIR WIRE TWISTED PAIR WIRE ANAL OG LOOP 1 ADDRESSABLE SMOKE DETECTOR WITH ISOLATOR BASE TWISTED PAIR WIRE ANAL OG LOOP 2 TWISTED PAIR WIRE ADDRESSABLE...
  • Page 60 Figure 35 Quad SLC Loop Adder Module Terminal Connections - Class A TWISTED PAIR WIRE ADDRESSABLE ALCN-960MISO or ALCN-4792MISO THERMAL SENSOR QUAD LOOP ADDER MODULE ANAL OG LOOP 1 ADDRESSABLE SMOKE DETECTORS Conventional 4-Wire Smoke Detectors, Heat Sensors and Manual Pull Stations ANAL OG LOOP 2 LEGEND...
  • Page 61 FNC-2000 Fire Network Controller Module The FNC-2000 Fire Network Controller modules are wired from terminals marked Line A, positive and negative (see specific cable recommended in Figure 36) to the Line B terminals of the next FNC-2000 module. Use of shielded cable is not recommended. Wire from Line B terminals to Line A of the next FNC-2000 module.
  • Page 62 FOM-2000-UM Fiber Optic Network Adder Module The FOM-2000-UM Fiber Optic Network Adder Module is wired with fiber optic cable. It is wired as shown in Figure 37 below. Connect L1 to L2 and L2 to L1 as shown in the Class A wiring of Figure 37. Refer to LT-6907 document for more wiring and installation information.
  • Page 63 Detection Module (DM-1008A) Terminal Connections Wire devices to terminals as shown below. See wiring tables, and Appendix A for electrical specifications and document LT-1023 for compatible devices. Figure 38 Hardwire Detection Module (DM-1008A) Terminal Connections INI 1+ SUPERVISED INITIATING CIRCUIT #1 CLASS B (ALARM ZONE) (POWER LIMITED) WIRING...
  • Page 64 Legend: SMOKE DETECTOR 3.9K 1/2W ELR LISTED S5434 MODEL MP-300 MANUFACTURED BY MIRCOM Notes: • The terminal blocks are “depluggable” for ease of wiring. • All power limited circuits must use type FPL, FPLR, or FPLP power limited cable. • SGM-1004A NACs are fully supervised and rated for 24 VDC Regulated, 1.7A...
  • Page 65 Relay Module (RM-1008(A)) Terminal Connections Relays are available as shown below. Hardwire Relay Module Terminal Connections RM-1008A Relay Module AUX RELAY 1 AUX RELAY 5 CONTACTS CONTACTS RLY 1 RLY 5 28 VDC, 1 AMP 28 VDC, 1 AMP RESISTIVE LOAD RESISTIVE LOAD AUX RELAY 2 AUX RELAY 6...
  • Page 66 Polarity Reversal and City Tie Module (PR-300) Wiring Wire PR-300 Polarity Reversal and City Tie Module (if used) as shown in Figure 40 below. Power Limited cable type FPL, FPLR or FPLP must be used. For USA installation, the installer must use Atlantic Scientific (Tel: 407-725-8000), Model #24544 Protective Device, or similar UL-Listed QVRG secondary protector, as shown.
  • Page 67 UDACT-300A Main Board Terminal Connections Wire the two telephone lines to RJ31X Connector terminals as shown in Figure 41 below. The UDACT-300A terminals are located on the top left hand corner of the board. If using a cellular or wireless service, use the Line 2 interface connection only Note: Most Authorities Having Jurisdiction (AHJ) do not allow the connection of premise telephones, see specifications for more information...
  • Page 68 6.10 Power Supply Connections The power supply is part of the main chassis. The ratings are outlined in the table below. Model Electrical Input Ratings Power Supply Total Battery Fuse on Main Current Module FX-4003-12N, FX-4003- 120 VAC, 60 Hz, 4A / 20 Amp, 1-1/4"...
  • Page 69 6.11 Wiring Tables and Information Table 10 Wiring Table for Initiating Circuits. Wire Gauge Maximum Wiring Run to Last Device (ELR) (AWG) 2990 4760 1450 7560 2300 12000 3600 19000 5800 30400 9200 Maximum loop resistance should not exceed 100 Ohms. Note: Table 11 Wiring Table for NACs...
  • Page 70 Table 12 Analog Loop Wiring Wire Gauge (use Loop Total (Out and In) Maximum twisted pair) Twisted Pair Wire Run (AWG) 10,000 3049 7971 2429 4980 1518 3132 Note: • Line capacitance shall not exceed 0.5 μF. • Inductance shall not exceed 1 mH. •...

  • Page 71: System Checkout

    System Checkout Before Turning the Power On 1. To prevent sparking, do not connect the batteries. Connect the batteries after powering the system from the main AC supply. 2. Check that all modules are installed in the proper location with the proper connections. 3.

  • Page 72: Indicators, Controls, And Operation

    Indicators, Controls, and Operation Refer to Figure 43 below for LED indicators, control buttons, and switches locations. Figure 43 Indicators and Control Location Queue controls and AC On CPU Fault indicators for Alarm, bi-coloured zone Indicator Indicator Supervisory, indicators and 16 Trouble and Monitor trouble indicators Ground Fault...
  • Page 73 Common Indicators Indicators Description The Buzzer is activated by any of the following Fire Alarm - Steady Supervisory Alarm - Fast Rate Trouble -Trouble Rate Buzzer Monitor -Configurable to sound at Trouble Rate If the Buzzer is turned on in response to a Non-Latching Trouble or Supervisory, it will be turned off if the condition causing it goes away and there is no other reason for it to be on.
  • Page 74 Common Controls 8.2.1 LCD Display: The display is a large 4 line by 20 character back-lit alphanumeric LCD. It displays information on the panel and its devices. There are cursor buttons for menu selection and control. Information provided by the LCD display is an alarm log, an event log, current levels, device information, verification and maintenance reports.
  • Page 75 8.2.3 Cursor Buttons These four buttons around the Enter Button are used for up (previous), down (latest), left, and right selection of items on the LCD Display. Enter Button This button is used to select a displayed item on the LCD Display. Cancel Button This button is used to cancel an operation.
  • Page 76 to operate specific NACs. Fire Drill is cancelled by pressing the button again (toggle switch), or if the Panel goes into a real Alarm. 8.2.7 General Alarm Cancel Button (Two Stage Only) If the Panel is not configured for Two Stage Operation, this button does nothing. If the Panel is configured for Two Stage Operation, activation of the General Alarm Cancel button while the Auto General Alarm Timer is timing (there is an Alarm in the Panel, but it is still in the First Stage), that timer is cancelled, and the General Alarm Cancel Indicator is on steady amber.
  • Page 77 Two Stage Operation In a two stage system, alarm inputs are either first stage (alert) inputs or second stage (general alarm) inputs. First stage inputs include inputs from the following types of circuits: non-verified alarm, verified alarm, sprinkler alarm, and water-flow alarm. Second stage inputs include alarms on the general alarm circuits, activation of the General Alarm button, or expiration of the Auto General Alarm timer.
  • Page 78 • If the Signal Silence LED is on, it turns off and the Auto Signal Silence timer, if configured, is restarted • The General Alarm Cancel LED if on, turns off Alarm inputs are latching: they remain active until system reset. If the system is configured for correlations, any second stage / general alarm Note: condition activates all NACs whether they are correlated or not.
  • Page 79 (open-circuit). This circuit is used for monitoring a trouble condition from an external device such as a Trouble-Only Mircom Series 500 Audio System. Both open and short circuits generate a non-latching trouble condition. 8.6.2 Indicating (Signal) Circuits Types...
  • Page 80 Indicating (Signal) Circuit Description Type For audible devices such as bells and piezo mini-horns that may not be silenced either manually or automatically. While sounding, these follow the pattern appropriate for the Non-Silenceable Signal condition: the configured evacuation code (default is temporal code) during single-stage alarm, or two-stage general alarm, or the alert code during a two stage system's alert (first) stage.
  • Page 81 8.6.3 Evacuation Codes Single stage codes On 100% of the time Continuous 3 of 0.5 second on, 0.5 second off then, 1.5 second pause Temporal Code 0.5 second on, 0.5 second off March Code 5 seconds on, 10 seconds off California Code Two-stage codes: Alert Code...

  • Page 82: Configuration

    Configuration The FleX-Net™ network system which includes FX-4003-12N, FX-4003-12NXT, FX-4009- 12N, FX-4017-12N, and FX-4000MNS is configured using MGC software MSW-036. NOTE: When setting up a system to use the Request, Grant, Deny functionality, if any nodes within that system have annunciators attached, the controls must be disabled on those annunciators (ancillary displays only).

  • Page 83: Typical Flex-Net™ System Layouts With Audio

    10.0 Typical FleX-Net™ System Layouts with Audio The following figures show two typical applications for the FleX-Net™ system with audio. Figure 45 below shows a typical FleX-Net™ system layout with the main lobby control panel as Node 1 and the combination Fire Alarm and Audio Network systems as Node 2 and 3. The diagram also shows addressable fire alarm loops, paging and telephone connections and audio cabinets.
  • Page 84 Figure 46 below shows the FleX-Net™ fire alarm and audio shown within the Integrated Network Fire/Audio cabinet as Node 2 and 3. Paging and telephone devices are hooked up to Nodes 2 and 3. Figure 46 Typical FleX-Net™ Network System with Audio and Non-Audio Nodes CACF Node 1 Node 2...

  • Page 85: System Components For The Integrated Fire/Audio Cabinet

    11.0 System Components for the Integrated Fire/Audio Cabinet 11.1 Network Fire Alarm Model Description Main network fire alarm board includes one SLC and four Class A/B NACs. The main board is mounted on a backplate which can FX-4000MNS hold up to 9 internal adder modules. This backplate mounts in the BBX-FXMNS enclosure.
  • Page 86 11.4 Adder Modules Model Description DM-1008A SGM-1004A Circuit Adder Modules RM-1008A 11.5 Auxiliary Modules Model Description PR-300 Polarity Reversal and City Tie Module UDACT-300A Digital Communicator/Dialer Module 11.6 Programmable Modules Model Description FDX-008W(KI) Fan Damper Module IPS-4848DS 48 Programmable Input Switches Module IPS-2424DS 24 Programmable Input Switches Module...

  • Page 87: Flex-Net™ Mass Notification System (Bbx-Fxmns) Enclosure

    12.0 FleX-Net™ Mass Notification System (BBX-FXMNS) Enclosure This enclosure can accommodate all existing modules, except the QMP-5101N Network Master Paging Control module and the QMT-5302N Master Firefighters’ Telephone. New models, QMP-5101NV vertical mounting master paging microphone and QMT-5302NV Master Telephone panels are used instead to mount within the BBX-FXMNS Enclosure. The BBX- FXMNS enclosure includes a backbox and a two part door and display deadfront chassis.
  • Page 88 The BBX-FXMNS backbox supports the QMB-5000N amplifier backplane and card cage which holds up to four amplifiers, the FX-4000MNS Fire Alarm main board chassis and PS-2040 Power Supply. Figure 48 BBX-FXMNS Backbox Dimensions and Contents BBX-FXMNS Backbox 16.5” Mounting Holes Dimensions QMB-5000N Audio Card Cage between...
  • Page 89 Figure 49 BBX-FXMNS Enclosure Complete View BBX-FXMNS FRONT DOORS AND DEADFRONT CHASSIS BBX-FXMNS BACKBOX...
  • Page 90 Figure 50 Mounting Vertical Microphone and Telephone Modules in the BBX-FXMNS Back side of BBX-FXMNS inner door Door Hinge Modules are mounted from the backside of the middle door using the screws provided Door Hinges Door Hinge...

  • Page 91: Mechanical Installation For The Qbb-5001(R) Expansion Audio Cabinet

    13.0 Mechanical Installation for the QBB-5001(R) Expansion Audio Cabinet Expansion audio cabinets are mounted as shown in Figure 51 below. The QBB-5001(R) is the backbox and door. The QBB-5001(R) backbox may be flush or surface mounted. The QBB- 5001TR is the metal flush trim. Install all cabinets and enclosures empty. Pull all required wiring in through the conduit holes provided (must be punched out).

  • Page 92: Bbx-Fxmns Audio Module Placement And Internal Wiring

    14.0 BBX-FXMNS Audio Module Placement and Internal Wiring The modules that mount into the audio card cage are the amplifier modules. Up to four amplifiers may be installed in each BBX-FXMNS enclosure with one of the four as a backup. Slot #1 is used for the ANC-4000 and/or TNC-5000 modules.

  • Page 93: Integrated Fire Alarm Connection

    15.0 Integrated Fire Alarm Connection The FX-4000MNS Chassis consists of the Network Fire Alarm main board and chassis. 15.1 Battery Power The power cable is used to provide power from the batteries to the FX-4000MNS Fire Alarm main board and the audio card cage motherboard. Power from the batteries is first directed to the Battery Disconnect Board, from this board the power is connected to the main fire alarm board and the audio card cage.

  • Page 94: Qbb-5001(R) Expansion Audio Cabinet Module Placement

    16.0 QBB-5001(R) Expansion Audio Cabinet Module Placement The modules that mount into the QBB-5001(R) expansion audio cabinet include the QPS- 5000N Power Supply, the QMB-5000B Motherboard, and the QBC-5000N Battery Charger. Module interconnects are shown in Figure 53. There is no module installed into Slot #1 of the QMB-5000B Motherboard, as shown below.
  • Page 95 the QMB-5000N (inside the BBX-FXMNS or Integrated Fire/Audio Cabinet) to the IN connector at the top left corner of the QMB-5000B Motherboard. Connect cable MD-525 from the QMB-5000B Motherboard (connection marked OUT in the top left corner) to the next expansion audio cabinet QMB-5000B Motherboard (connection marked IN) if another audio cabinet is used.

  • Page 96: Installing And Removing Amplifiers

    17.0 Installing and Removing Amplifiers ATTENTION: Improper installation or excessive force will damage the motherboard and modules being installed or removed. 17.1 Installing QAA Amplifier Modules 1. Hold the amplifier to be installed by the backplate edges. Do not handle, push or pull any of the components on the amplifier (especially not the transformer) as this will damage those components.

  • Page 97: Multiple Qbb-5001/R Cabinet Connections

    When multiple QBB-5001/R audio cabinets are used in an installation, each has its own QPS- 5000N Power Supply, QBC-5000N Battery Charger, and batteries. A total of three audio cabinets may be used by simply interconnecting with Mircom MD-525 Extension Cables from the QMB-5000N "Out" Connector, to the "In" Connector on the next QMB-5000B motherboard.

  • Page 98: Audio Network Card And Telephone Network Card

    19.0 Audio Network Card and Telephone Network Card Each Integrated Fire/Audio Cabinet requires an ANC-4000 Audio Network Controller Card. The TNC-5000 Telephone Controller Network card is necessary only if Telephone circuits are required. Below is a diagram for mounting both audio and telephone cards into the large network fire alarm chassis, FX-4009-12N.

  • Page 99: Audio Amplifier Wiring

    WIRING MANUFACTURED BY SPEAKER Class A or B EXAMPLE MIRCOM 30 WATTS MAX Notes: All circuits are power limited and supervised. •Cut jumper J1 when using an isolator. •There are two fuses on this board. Both are 4A fast blow.
  • Page 100 Figure 58 Using a Speaker Isolator CUT JUMPER JP1 WHEN USING A SPEAKER ISOLATOR Note: When using a speaker isolator (SIS-204 or SISA- 204 for use in Canada only), jumper JP1 (top left- hand corner, component side) must be cut on the QAA-5230-70/25 and on the QAA-5160-70/25.
  • Page 101 QAA-5230S-525-70/25 22 K, 1W ELR TERMINAL BLOCK 1/2 OF TERMINAL BLOCK MODEL MP-302 SPEAKER MANUFACTURED BY ZONE B 15 Watts MIRCOM 25 Watts CLASS B 22 K, 1W ELR 30 WATTS 1/2 OF MAX EACH MODEL MP-302 SPEAKER ZONE MANUFACTURED BY...
  • Page 102 25 Volts. Figure 60 QAA-5415-70 or QAA-5415-25 Wiring QAA-5415-70 OR QAA-5415-25 22K, 1W ELR TERMINAL BLOCK MODEL MP-302 ZONE D SPEAKER MANUFACTURED BY MIRCOM 22K, 1W ELR MODEL MP-302 ZONE C SPEAKER MANUFACTURED CLASS B WIRING BY MIRCOM 15 WATTS...
  • Page 103 Figure 61 Using a Speaker Isolator with the QAA-5415-70 or QAA-5415-25 Amplifiers QAA-5415-70/25 AMPLIFIER CUT JUMPER OVER U3 WHEN USING A SPEAKER ISOLATOR JUMPER Note: When using a speaker isolator (SISA-204 or SISA-204 for use in Canada only), jumper JP1 (top left-hand corner, component side) must be cut on the QAA-5230-70/25 and on the QAA-5160-70/25.
  • Page 104 Figure 62 QAA-4CLA Class A Converter For QAA-5415-70/25 Amplifier...
  • Page 105 Figure 63 QAA-4CLAS Class A Converter For QAA-5230S-70/25 Amplifier...
  • Page 106 MODEL MP-301 SPEAKER MANUFACTURED 60 WATTS MAX BY MIRCOM Notes: • All circuits are power limited and supervised. • There are two fuses on this board. Both are 8A fast blow. • See speaker wiring chart for wire gauge selection.
  • Page 107 Table 13 Wiring Chart for 70V Speakers Total Maximum Wiring Run To Last Device (ELR) Power 18AWG 16AWG 14AWG 12AWG Watts 2500 4000 1219 6000 1828 8000 2438 1500 2500 4000 1219 6000 1828 1200 2000 3500 1066 Notes for Wiring Charts: For each speaker zone, select the total zone power.
  • Page 108 20.5 Backup Amplifier Any amplifier may be designated as a backup amplifier when backup is required. It should be installed in any audio cabinet and in the right-most slot position of a QMB-5000B backplane. Figure 65 QAA-5160-70/25 Amplifier (Backup Application) Any amplifier may be designated as the backup amplifier and this backup...

  • Page 109: Amplifier Displays & Controls

    21.0 Amplifier Displays & Controls Figure 66 Audio Cabinet Displays and Controls PAGE PAGE PAGE PAGE PAGE PAGE PAGE EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC EVAC...

  • Page 110: Qbb-5001(R) Amplifier Installation

    22.0 QBB-5001(R) Amplifier Installation The following instructions are based on the assumption that the fire alarm is already installed. 1. Install the QBB-5001(R) Audio Backbox and door in the desired location. 2. Install the QMB-5000B Motherboard / Card-Cage into the backbox. 3.

  • Page 111: Audio Configuration

    23.0 Audio Configuration The configuration of the FleX-Net™ is accomplished via the MSW-036 Personal Computer based Configurator Software.

  • Page 112: Anc-4000 Audio Network Controller Module

    24.0 ANC-4000 Audio Network Controller Module Figure 67 ANC-4000 Audio Network Controller board Connects to TNC-5000 Telephone Network Controller Module P7 AMPS Interface Heartbeat RESET/CPU Fail System OK COMM RX COMM TX LEDs for Plugs into the Audio/CLASS D TX Information QMB-5000N Audio/CLASS D RX...

  • Page 113: Anc-4000 Wiring

    25.0 ANC-4000 Wiring Figure 68 ANC-4000 Wiring Diagram JW7 JW8 PAGING BUS + - + - + - S + - L + - S + - S + - S Alternate G.A. RS-485 Power Input Wire the Paging Bus Microphone to all other ANC-4000 and push to...
  • Page 114 Figure 69 Audio Paging Bus Wiring CLASS A WIRING Paging Paging Bus Out Bus In ANC-4000 ANC-4000 Paging Paging Node 4 Node 5 Bus In Bus Out Paging Paging Bus Out Bus In ANC-4000 ANC-4000 Paging Paging Node 3 Bus In Node 6 Bus Out Additional ANC-4000s...

  • Page 115: Qmp-5101Nv Vertical Paging Control Module

    26.0 QMP-5101NV Vertical Paging Control Module The QMP-5101NV Paging Module is a vertical paging unit which fits into the new BBX-FXMNS Enclosure. It mounts on the inside chassis (part of the BBX-FXMNS). Connections and terminal wiring are the same as for the QMP-5101N. Refer to Figure 72 for wiring instructions for both the QMP-5101NV and QMP-5101N paging control modules.

  • Page 116: Qmp-5101N Network Master Paging Control Module

    27.0 QMP-5101N Network Master Paging Control Module The QMP-5101N Network Master Paging Control Module mounts into the BB-5008 and BB- 5014 backboxes. The QMP-5101N Network Master Paging Control Module connects via a ribbon cable to the first QAZT-5348DS or QAZT-5302DS Zoned Selector Panel and to the previous display module.
  • Page 117 Figure 72 QMP-5101NV and QMP-5101N Network Master Paging Control Module Connections and Terminal Blocks TO NEXT MICROPHONE (IF THIS IS THE LAST FROM PREVIOUS MICROPHONE, MICROPHONE PLACE EOL 3K9 ohm RESISTOR HERE SHIELD SHIELD BETWEEN + and - OF PTT TERMNALS). SHIELD SHIELD TO QAZT-5348DS or QAZT-5302DS SELEC-...

  • Page 118: Qmp-5101Nv/N Network Paging Wiring

    QMP-5101NV/N Network Paging Wiring 28.0 Figure 73 QMP-5101NV/N Network Master Paging Control Module Wiring to the ANC-4000 Audio Network Controller Module QMP-5101N/V Network Master Paging Module Master microphone and push to talk button are wired by Factory to these terminals This connection to Aux Power is required when the ANC-4000 is mount-...

  • Page 119: Qazt-5348Ds And Qazt-5302Ds Zoned Paging Selector Panels

    29.0 QAZT-5348DS and QAZT-5302DS Zoned Paging Selector Panels Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Paging Each QAZT-5348DS annunciates and Paging Paging Paging...

  • Page 120: Paging Operation

    30.0 Paging Operation This section describes the controls and indicators on the QMP-5101N and QMP-5101NV Master Paging Control Modules and the QAZT-5302DS Paging Selector Modules. 30.1 QMP-5101N/QMP-5101NV LEDs Warden Page Illuminates steady green to indicate that the Warden Page function is active. All Call Illuminates steady green to indicate that the All-Call function is active.
  • Page 121 30.2 QMP-5101N/QMP-5101NV Pushbutton Controls Warden Page Button When depressed, the Warden Page button enables voice paging from the firefighters' telephone (if connected) to all zones selected for paging, unless page inhibit is active. Note that pressing PTT will not result in any paging activity unless there are zones selected for paging.

  • Page 122: Tnc-5000 Telephone Network Controller Module

    TNC-5000 Telephone Network Controller Module 31.0 31.1 Module Mounting Locations The TNC-5000 Telephone Network Controller board can be mounted in two ways. The TNC- 5000 Telephone Network Controller Board is mounted above (beside) the ANC-4000 Audio Network board, both are mounted on a metal backplate and the ANC-4000 plugs into slot 1 on the QMB-5000N audio backplane of the BBX-FXMNS, see Figure 74.
  • Page 123 Mechanical Installation of the TNC-5000 within the BB-5008 and Figure 75 BB-5014 Main fire alarm board Mounting plate TNC-5000 ANC-4000 31.2 Typical Addressable Telephone Set-up The typical addressable telephone set-up is with an addressable fire alarm system using the TNC-5000 and from the TNC-5000 to the Master Telephone (QMT-5302N(V)). The selector panels (QAZT-5348DS or QAZT-5302DS) are connected to the Master Telephone by cable only.
  • Page 124 31.3 Connectors and Terminal Locations Refer to Figure for connector and terminal locations. Table 3 below shows the cable connections and jumpers required and additional wiring. Table 3: TNC-5000 Connectors and Terminals TNC-5000 Connects to Connector and Terminals P10 Cable P11 on the ANC-4000 Audio Network Controller Module.
  • Page 125 31.4 TNC-5000 Telephone Wiring Figure 78 Telephone Bus Wiring Diagram Tel. Bus Tel. Bus TNC-5000 TNC-5000 Tel. Bus Tel. Bus Tel. Bus Tel. Bus TNC-5000 TNC-5000 Tel. Bus Tel. Bus Tel. Bus Tel. Bus TNC-5000 TNC-5000 Tel. Bus Tel. Bus +, - , Shield +, - , Shield Tel.
  • Page 126 Zones 1 to 5 are wired to telephones via MIX-M500FP(A) addressable control modules. Only Zone 1 is wired to the Master Telephone (if used) at the main fire alarm center, otherwise Zone 1 is wired as another telephone zone when a master telephone is not required. Figure 79 TNC-5000 Telephone Zone Wiring FROM PREVIOUS FIREPHONE MODULE.

  • Page 127: Qmt-5302Nv Vertical Master Telephone

    32.0 QMT-5302NV Vertical Master Telephone The QMT-5302NV Vertical Master Telephone Module fits into the BBX-FXMNS Enclosure. The master telephone is mounted to the inside chassis and field wiring is on the BBX-FXMNS backbox. Connections and terminal wiring are shown in the following instructions. Figure 80 QMT-5302NV Master Firefighters’...
  • Page 128 32.1 QMT-5302NV Connections The connection required on the QMT-5302NV telephone board is the ribbon cable from the previous display module to P1 or IN connector on the bottom center of the board and the OUT connection goes to the IN connector of the next display board. The master telephone positive and negative terminals (located on the back of the QMT- 5302NV) connect to the TNC-5000 Zone 1 postive and negative terminals with twisted pair wires.

  • Page 129: Qmt-5302N Master Firefighters' Telephone

    33.0 QMT-5302N Master Firefighters’ Telephone The QMT-5302N mounts into the BB-5008 and BB-5014. QMT-5302N Network Master Firefighters' Telephone Control Module is used in conjunction with the FleX-Net™ Fire Alarm system at the CACF Node. Slide-in labels (NP-6657) are supplied with the Master Telephone. Place labels as shown in Figure 81.

  • Page 130: Qmt-5302N Connections

    34.0 QMT-5302N Connections The connections required on the QMT-5302N Network Master Firefighters’ Telephone Control Module are the cable from the previous display module to P1 or IN connector on the bottom left of the board and the OUT connection goes to the IN connector of the next display board. The master telephone positive and negative terminals connect to the TNC-5000 Zone 1 positive and negative terminals with twisted shielded pair wires.

  • Page 131: Qazt-5348Ds And Qazt-5302Ds Firefighters' Telephone Selector Panel

    35.0 QAZT-5348DS and QAZT-5302DS Firefighters’ Telephone Selector Panel Figure 83 QAZT-5348DS and QAZT-5302DS Network Firefighters' Telephone Selector Panels Each QAZT-5348DS annunciates and controls up to 48 telephone Telephone Telephone Telephone Telephone Telephone Telephone zones. Each QAZT-5302DS Telephone Telephone Telephone Telephone Telephone Telephone annunciates and controls up to 24...
  • Page 132 Figure 84 QAZT-5348DS Telephone and/or Paging Selector Board Ribbon Cable connects here on QAZT-5348DS and goes to the next QAZT-5348DS or display module Ribbon IN. PROG Ribbon Cable is permanently attached here and connects to Ribbon OUT connector of Master Telephone, Mas- ter Paging Microphone or previous QAZT-5348DS.

  • Page 133: Telephone Operation

    36.0 Telephone Operation 1. When any telephone zone rings (the local buzzer sounds intermittently, and the green zone LED and Incoming Call LED flash) press that zone's button (on the selector panel QAZT-5302DS) once to answer. Once any one zone has been answered, calls from any other zone will cause that zone's green LED and the Incoming Call LED at the master telephone to flash and the buzzer will sound.

  • Page 134: Appendix A: Specifications

    37.0 Appendix A: Specifications Main Fire Alarm Chassis (FX-4017-12N) Main Fire Alarm Chassis (FX-4003-12N/-12NXT) General Same as FX-4009-12N except: Larger Chassis has capacity for 3 display modules and 17 adder One Analog Loop capable of monitoring 240 MGC MIX-4000 modules. Series Sensor and Modules Main Fire Alarm Chassis (FX-4000MNS) 22 VDC, 400 mA max, max loop resistance 40...
  • Page 135 FOM-2000-UM Fiber Optic Module FNC-2000 Network Controller Module standby: 15 mA standby: 190 mA Current Consumption: Current Consumption: alarm: 15 mA alarm: 190 mA ANC-4000 Audio Controller Module RAXN-4000LCDG Annunciator standby: 255 mA Current Consumption: 24V DC nominal. Standby: 139 mA Max., All LED's "On": 164 mA Max alarm: 265 mA TNC-5000 Telephone Controller Module...
  • Page 136 37.1 ULI/ULC Integrated Fire Alarm and Audio Panel Specifications Note: All circuits are power limited, unless specified otherwise. 37.1.1 PS-2040 Power Supply • 0 to 49 degrees Celsius, 0 to 93 + or - 2% RH (non-condensing) operating range • Power input: 120 VAC, 60Hz, 12A or 240 VAC, 50Hz, 6A (primary), Not Power-limited •...
  • Page 137 • Current consumption: standby: 55mA alarm: 350mA, plus 75mA/watt speaker power 37.1.12 Model QMP-5101N or QMP-5101NV Paging Microphone • Mounts in Mircom BB-1000, BB-5000, FX-LOC, and BBX-FXMNS (for QMP-5101NV) enclosures • Current Consumption: standby: 3mA alarm: 7mA 37.1.13 Model QAZT-5348DS or QAZT-5302DS Paging Selector Panel •...
  • Page 138 37.1.14 Model QMT-5302N or QMT-5302NV Master Telephone • Mounts in Mircom BB-1000, BB-5000, FX-LOC, and BBX-FXMNS enclosures • Current Consumption: standby: 1mA alarm: 13mA 37.1.15 Model QAZT-5348DS or QAZT-5302DS Telephone Selector Panel • Mounts in Mircom BB-1000, BB-5000, FX-LOC, and BBX-FXMNS enclosures •...

  • Page 139: Appendix B: Power Supply And Battery Calculations

    38.0 Appendix B: Power Supply and Battery Calculations Power Requirements (All currents are in amperes) Total Total Model Number Description Standby Alarm Standby Alarm FX-4003-12N/12NXT Main Chassis (12 Amp) 0.310 0.733 FX-4017-12N Main Chassis (12 Amp) 0.310 0.733 FX-4009-12N Large Main Chassis (12 Amp) 0.310 0.733 ALCN-960MISO and...
  • Page 140 LCD display (or for the RAXN-4000LCDG a graphical display) which uses a simple menu system complete with a directional key pad and switches for Enter, Menu, Cancel and Info. For more information see Mircom documents LT-895MP and LT-6033MP. Annunciator Models: Main Annunciator Chassis with Common Indicators and Controls.

  • Page 141: Appendix C: Dip Switch Settings

    39.0 Appendix C: DIP Switch Settings FX-400X-XX Network Main Board Address Setting (DIP SWITCH SW2) SW2 DIP SWITCHES Node Address SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8...

  • Page 142: Appendix D: Alarm Verification Timing

    ANC-4000 Board Address Setting (DIP SWITCH SW1) ADDR SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 ALCN-960MISO/ALCN-4792MISO Loop Adder Module Address Setting (DIP SWITCH SW1) ADDR SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8 RAXN-4000LCD/RAXN-4000LCDG Remote Annunciator Address Setting (DIP SWITCH SW1) ADDR SW1-1 SW1-2...

  • Page 143: Appendix E: Wiring For Addressable Supervised Output Module

    Appendix E: Wiring For Addressable Supervised Output Module 41.0 CSIS - 202A CSIS - 202A Supervised Signal Supervised Signal BPS -1100 Isolator #1 Isolator #2 Booster Power Supply ROOM1 ROOM 2 ROOM1 ROOM 2 RETURN RETURN RETURN RETURN ROOM1 ROOM 2 ROOM1 ROOM 2 SIGNAL...

  • Page 144: Appendix F: Power Supply & Batteries For Audio

    42.0 Appendix F: Power Supply & Batteries for Audio Use the form below to determine the required main chassis and secondary power supply (batteries). IMPORTANT NOTICE The main AC branch circuit connection for Fire Alarm Control Unit must provide a dedicated continuous power without provision of any disconnect devices.

  • Page 145: Appendix G: Fxmns Used As A Mass Notification System (Acu)

    Appendix G: FXMNS Used as a Mass Notification System (ACU) The MNS portion of a complete Mircom FleX-Net™ Network Fire Alarm system consists of a BBX-FXMNS Enclosure (see Node 2 in figure below). The BBX-FXMNS includes a RAXN- 4000LCD Annunciator which is designated an ACU (Autonomous Control Unit) and a Master Microphone to provide emergency audio.
  • Page 146 43.1 QMP-5101N Network Paging Wiring for Mass Notification QMP-5101N Network Master Paging Control Module Wiring to the ANC-4000 Audio Network Controller Module MNS - ACU FX- LOC(R) TWISTED QMP-5101N Network QMP-5101N Network SHIELDED Master Paging Module Master Paging Module PAIR CABLE Daisy chain PTT and MIC to next FX-LOC(R).
  • Page 147 43.2 Configuration for Mass Notification There are two groups that can be created for the nodes; one group is the fire/central control and the second is mass notification. In order to have this distinction, all zones have to be assigned a “Zone Priority”. Priority can be high, low, normal or a percentage of + or - increments of 5.
  • Page 148 This screen capture shows input zone priority settings for the Mass Notification Node 2 43.3 FX-LOC(R) Active As part of the Mass Notification requirements, an RAX-1048TZDS Zone Annunciator is part of the MNS. Configure one zone of the RAX-1048TZDS per each FX-LOC(R) connected to the MNS (ACU).

  • Page 149: Appendix H: Apb-200/Coa Sounder Bases

    44.0 Appendix H: APB-200/COA Sounder Bases The FleX-Net™ Network Fire Alarm system can accommodate up to 32 APB-200/COA sounder bases per panel (node). The sounder base audio is synchronized on the same loop basis. Below is a wiring diagram for connecting the sounder bases to auxiliary power with supervision.

  • Page 150: Appendix I: Label Requirements For Zone Identification

    45.0 Appendix I: Label Requirements for Zone Identification If individual zones are used for various applications, the labelling of these zones must be in accordance with ULC/CAN S527-11 Table 2; of which is partially included below: LABEL DESIGNATIONS IN ENGLISH DESCRIPTION OF FUNCTION Alarm Signal Activation or Circuit Or Area Evacuation Manual Control...

  • Page 151: Warranty And Warning Information

    As the only individual in contact with system users, please bring each item in this warning to the attention of the users of this Mircom System. Failure to properly inform system end-users of the circumstances in which the system might fail may result in over-reliance upon the system.
  • Page 152 11. Battery Failure. If the Mircom System or any device connected to the system operates from batteries it is possible for the batteries to fail. Even if the batteries have not failed, they must be fully charged, in good condition, and installed correctly.
  • Page 153 20. Integrated Products. Mircom System might not function as intended if it is connected to a non-Mircom product or to a Mircom product that is deemed non-compatible with a particular Mircom System.
  • Page 154 U.S.A © Mircom 20 25 Interchange Way 4575 Witmer Industrial Estates Printed in Canada Vaughan, ON L4K 5W3 Niagara Falls, NY 14305 Subject to change without prior notice Tel: (888) 660-4655 Tel: (888) 660-4655 (905) 660-4655 (905) 660-4655 www.mircom.com Fax: (905) 660-4113...

This manual is also suitable for:

Flex-net fx-4000Flex-net fx-4000n

Table of Contents

Save PDF
