2N IP Style Installation Manual page 98

Supported cards in 13.56 MHz NFC version (only card ID is read)
ISO14443A (Mifare, DESFire)
PicoPass (HID iClass)
FeliCa
ST SR(IX)
®
2N Mobile Key
Supported secured cards in 13.56 MHz NFC version
HID SE (Seos, iClass SE, Mifare SE)
Maximum H – field strength at 10 m for 125 kHz version:
Maximum H – field strength at 10 m for 13.56 MHz version:
Bluetooth
Bluetooth 4.2 in compliance with BLE (Bluetooth Low Energy)
Security: asymmetric RSA-1024 and symmetric AES-128 encryption
Range: adjustable (short ~ 0.5m, medium ~ 2m, long ~ up to 10m)
Support of mobile applications: Android 6 and higher, iOS 12 and higher
Touch display
Resolution: 10.1'' 1280 x 800 TFT IPS
Contrast ratio: 800
Brightness: 900 cd/m2
Viewing angle: 85 ° from any direction
Numeric keypad: touch numeric keypad
Touch buttons: touch display
Directory: residential / business (for 10 000 users)
I/O module (optional)
External
Dimension: 43 (W) x 31.5 (H) x 1.5 (D) mm
Wiegand module (optional)
External
Dimensions: 43 (W) x 31.5 (H) x 1.5 (D) mm
Mechanical properties
Cover: Hardened glass
2N TELEKOMUNIKACE a.s., www.2n.cz
2
1.492e-3 W/m
2
3.747e-4 W/m
98/105
