Specifications:
Passive switch: NO and NC contacts, up to 30 V / 1 A AC / DC
Switched output:
Where the security relay is fed from the intercom, 9 to 13 V DC is available on
the output depending on the power supply (PoE: 9 V; adapter: source voltage of
minus 1 V) / 400 mA DC.
Where the security relay is fed from an external power supply, 12 V / 700 mA DC
is available on the output.
Dimensions: (56 x 31 x 24) mm
Weight: 20 g
Installation:
®
Install 2N Security Relay
electric lock inside the area to be secured (typically behind the door). The device is
powered and controlled via this two-wire cable and can thus be added to an existing
installation. Thanks to its compact dimensions, the device can be installed into a
standard mounting box.
Connection:
®
Connect 2N Security Relay
To the active output (OUT1)
Connect the electric lock to
To the switched output
To the passive output in series with the external power supply
The device also supports a Departure button connected between the 'PB' and '-
HeliosIP / IP Intercom terminals. Press the Departure button to activate the output for
5 seconds.
Status Signaling:
Green LED Red LED
flashing off
2N TELEKOMUNIKACE a.s., www.2n.cz
onto a two-wire cable between the intercom and the
to the intercom as follows:
®
2N Security Relay
Status
Operational mode
output as follows:
