2N IP Style Installation Manual page 63

Caution
Purchase a frame / mounting box for the extending modules to be
connected according to the type of installation. This does not apply to
the I/O, Wiegand and tamper switch extending modules.
Module Power Supply
®
All the 2N IP Style
The available bus power output depends on the power supply type. The basic unit can
use a 4A power supply to increase the power available to the modules connected.
Power supply Specification
External supply 12 V ±15 % / 4 A DC
PoE+ 802.3at
Combined External supply + PoE+
Infopanel Module
The Infopanel module (
and is used for inserting and backlighting the printed information.
The module contains two
These two connectors are fully interchangeable and can be used either as inputs
from the basic unit or outputs to other modules.
If this module is the last one on the bus, one of the connectors remains
unconnected.
The module package includes a 220 mm long interconnecting cable.
Name tag dimensions: 69.2 (W) x 86.7 (H) mm (dimensional tolerance: +0;
mm).
Refer to www.2n.cz
2N TELEKOMUNIKACE a.s., www.2n.cz
modules, except for the tamper switch, are powered from a bus.
Part No. 9155030
®
2N IP Style
for the printing template.
Available power output
up to 48
up to 21.6 W
®
) is one of the 2N
bus connectors.
IP Verso system elements
63/105
− 0.5
