It is assumed that the chassis (
2.2.2 Mounting Box Installation
recommended length of the accessible cables is 35 cm.
Unscrew the connector cover on the back of the device. Thread all of the
unterminated cables (i.e. without terminals, end pieces, etc.) through the bushing on
the inside of the connector cover. After threading the cables through the bushing, fit
the required end pieces (1).
Fold out the mounting bracket located at the bottom of the chassis or flush mounting
box. Fit the profiles on the device back onto the mounting bracket and slide them
down to the lowest possible position, anchoring the device by snapping it into place
(2A).
Connect all the cables to the device (2B). The mounting bracket provides sufficient
support for cable installation and so it is unnecessary to support the device in any
way.
After connecting and securing the superfluous cabling in the clips (3A), screw the
connector cover back on (3B), fold in the device towards the chassis or the flush
mounting box (4A) and then press downwards (4B) to seal the installation.
Now all you have to do is lock the position by tightening the two screws inside the
device using an Allen key (5).
General Mounting Principles
Tip
Select flush mounting where possible. This makes the product elegant
looking, more vandal resistant and more secure.
You are advised to purchase the flush mounting boxes and chassis in
advance and commission a building company to do the masonry for you,
for example.
2N TELEKOMUNIKACE a.s., www.2n.cz
2.2.1 Chassis Installation
) and all of the required cables have been installed. The
) or the flush mounting box (
41/105
