Installation manual 2N® IP
Safety





v.2.15
www.2n.com

Advertisement

Table of Contents
loading

Related Manuals for 2N IP Safety

Summary of Contents for 2N IP Safety

  • Page 1     Installation manual 2N® IP Safety           v.2.15 www.2n.com...

  • Page 2: Table Of Contents

    Installation manual 2N® IP Safety Content: • 1. Product Overview • 1.1 Components and Associated Products • 1.2 Terms and Symbols • 2. Description and Installation • 2.1 Before You Start • 2.2 Mechanical Installation • 2.3 Electric Installation •...

  • Page 3: Product Overview

    A wide range of settings allow for a variety of applications. ®  IP Safety is very easy to install. All you have to do is connect the system into your LAN via a network cable and feed it from a 12 V power supply or your PoE supporting LAN.

  • Page 4: Components And Associated Products

    Installation manual 2N® IP Safety • Up to 20 user time profiles • Video codecs (H.263, H.263+, H.264, MPEG-4, JPEG) • Audio codecs (G.711, G.729, G.722, L16/16 kHz) • HTTP server for configuration • SNTP client for time synchronisation with server •...
  • Page 5 Axis Part No. 01355-001 • control of two electric locks • possibility of connecting additional switch ® IP Safety units can wall mounted without requiring any additional accessories. Use the appropriate mounting box (see below) for plasterboard and flush mounting. 5 /  82...
  • Page 6 Installation manual 2N® IP Safety Flush Mounting Box • Mounting frame • Orange 2N Part No. 9152000 • Aluminum Axis Part No. 01356-001 • Good to cover the edge of the intercom in flush or plasterboard installation. • Brick flush mounting box •...
  • Page 7 Installation manual 2N® IP Safety • Plasterboard flush mounting box • Dimension: 237 x 129 x 70 mm 2N Part No. 9151002 • Hole: 237 x 118 mm Aixs Part No. 01349-001 7 /  82...
  • Page 8 Installation manual 2N® IP Safety Mounting Accessories • Gooseneck stand • Height 120 cm (47 inch) to the top of the intercom 2N Part No. 9151005 Axis Part No. 01351-001   8 /  82...
  • Page 9 Installation manual 2N® IP Safety • Gooseneck stand double • Height 115 cm (45”) and 203 cm (80”) 2N Part No. 9151007 Axis Part No. 01550-001 • Installation adapter (US only) 2N Part No. 9151006 Axis Part No. 01352-001 9 /  82...
  • Page 10 The elegant internal touch panel, 2N Indoor Touch 2N Part No. 91378375 2.0, is suitable for all 2N IP intercoms. On the panel’s Axis Part No. 01668-001 display not only can you find out who is at the door, but also start a conversation with the visitor, open the 2N Part No.
  • Page 11 The elegant internal touch panel, 2N Indoor Touch 2N Part No. 91378375WH 2.0, is suitable for all 2N IP intercoms. On the panel’s Axis Part No. 01669-001 display not only can you find out who is at the door, but also start a conversation with the visitor, open the 2N Part No.
  • Page 12 Installation manual 2N® IP Safety ® •  IP Handset • answering unit 2N Part No. Axis Part No. • white color 1120101W 02518-001 ® •  IP Handset • answering unit 2N Part No. Axis Part No. • black color 1120101B 02519-001  ...
  • Page 13 Installation manual 2N® IP Safety IP Telephones • Yealink SIP T58A IP video phone  • simple operation 2N Part No. 91378360 • HD quality video calls Axis Part No. 01586-001 • A display-equipped extender EXP50 (Part No. 91378363) can be added to the phone delivery to make up to 60 speed dialings.
  • Page 14 Installation manual 2N® IP Safety Electric Locks Part No. 11202101 • Mini electronic doorstrike series 5  • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular • short sheet metal front cover version (130 mm) •...
  • Page 15 Installation manual 2N® IP Safety Part No. 11202102-L • Mini electronic doorstrike series 5 – with momentum pin, long • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular •...
  • Page 16 Installation manual 2N® IP Safety Part No. 11202104 • Mini electronic doorstrike series 5 – door signaling • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular • including a door state monitoring micro switch: open/closed •...
  • Page 17 Installation manual 2N® IP Safety Part No. 11202105-L • Mini electronic doorstrike series 5 – fail-safe, long • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular • under voltage: opener secured, blocked •...
  • Page 18 Electromechanical lock SAM 7255 • 72/55 self-locking lock with panic function • A key is necessary for door opening from the outside (or an electric pulse from a connected 2N IP intercom / reader). • convenient solution for emergency exits Part No.
  • Page 19 • 92/35 self-locking lock with panic function • A key is necessary for door opening from the outside (or an electric pulse from a connected 2N IP intercom / reader). • convenient solution for emergency exits Part No. 11202301 •...
  • Page 20 Installation manual 2N® IP Safety Part No. 11202303 • Cable protector FX300G • Provides secure passage and protection of the supply cable between the door frame and the door leaf. • 440 mm length Part No. 11202304 • Cable protector FX500G •...
  • Page 21 Installation manual 2N® IP Safety Part No. 11202501 • Magnetic handle P300RP • fully replaces a mortise lock and handle • under voltage: door cannot be opened • at voltage interruption: magnets get disconnected, door opens • suitable for wooden, metal and glass doors Part No.
  • Page 22 Installation manual 2N® IP Safety  • FAQ: Electric locks – Difference between locks in 2N IP intercoms accesories Power Supply • PoE injetor – with EU cable • PoE injector – with US cable Part Numbers: • For power supply of intercom via...
  • Page 23 Installation manual 2N® IP Safety • 12 V transformer • For 230 V mains voltage. Part No. 932928 • For external power supply of the lock with 12 V AC voltage. Additional Modules • Additional switch with normally open/closed contact and 12 V switched output.
  • Page 24 Installation manual 2N® IP Safety • External IP Relay – 1 output • Standalone IP device which can be controlled 2N Part No.  9137410E by HTTP commands sent by 2N IP intercom, which Axis Part No. 01397-001 can thus control devices on unlimited distance. 24 /  82...
  • Page 25 External IP Relay – 4 outputs, PoE • Standalone IP device which can be controlled by HTTP 2N Part No. 9137411E commands sent by 2N IP intercom, which can thus Axis Part No. 01398-001 control devices on unlimited distance. •...
  • Page 26 • Induction Loop • An induction loop transmits sound wirelessly from the 2N Part No. 9159050 2N IP intercom to the earphones of people with Axis Part No. 01391-001 hearing disabilities and enables them to hear and perceive sounds better. • Stabilised 12 V / 2 A power supply needs to be used when no PoE is available.
  • Page 27 Installation manual 2N® IP Safety License • Enhanced Audio 2N Part No. 9137905 • Enhanced Video  2N Part No. 9137906 • Enhanced Integration   2N Part No. 9137907 • Enhanced Security 2N Part No. 9137908 • Gold 2N Part No. 9137909 •...

  • Page 28: Terms And Symbols

    Installation manual 2N® IP Safety • Lift Module  2N Part No. 9137916  • Refer to the Configuration Manual for 2N IP intercoms, Subs. 3.2 Function Licensing for details.  • For more accessories and particular advice please contact your local distributor of 2N products.

  • Page 29: Description And Installation

    • 2.3 Electric Installation • 2.4 Extending Module Connection 2.1 Before You Start Product Completeness Check ® Before you start please check the contents of your 2N  IP Safety delivery: ® • 1x 2N  IP Safety • 1x Torx 10 / Torx 20 double-ended wrench •...
  • Page 30 Installation manual 2N® IP Safety Common Mounting Principles  • Select flush mounting where possible to make your product elegant looking, more vandal resistant and more secure. • You can purchase the flush mounting box in advance and hire an installation professional to make the basic installation work.
  • Page 31 Remember that dowels of poor quality may easily get loose and fall out of the wall! ® • Stainless steel screws are used for the 2N IP Safety assembly. Other screws than stainless steel ones corrode soon and may aesthetically deteriorate the surrounding environment! •...
  • Page 32 Installation manual 2N® IP Safety  Warning Be sure keep strictly the hole dimensions while mounting the device into classic bricks without the flush mounting box as shown in the picture with dimensions. Flush Mounting – Classic Bricks What You Need: •...
  • Page 33 Installation manual 2N® IP Safety Flush Mounting – Thermally Insulated Wall What You Need: • Longer screws (depending on the thermal insulation thickness) • Hole: (112 x 220 x 70) mm Cut out the thermal insulation layer using the template (the same as for classic brick wall).
  • Page 34 ® Suppose you intend to install your 2N IP Safety unit into a wall made of hollow bricks. Note that the external side of the bricks gets damaged by cutting and the dowels cannot practically be fixed into the thin internal part of the bricks. Therefore, use the brick flush mounting box and follow the instructions included therein.
  • Page 35 Installation manual 2N® IP Safety 35 /  82...
  • Page 36 Installation manual 2N® IP Safety Flush Mounting – Plasterboard What You Need: • Plasterboard flush mounting box, Part No. 9151002  • Hole: (118 x 237) mm Use the plasterboard flush mounting box and follow the instructions included therein. Wall Mounting What You Need:  ...
  • Page 37 Installation manual 2N® IP Safety  Caution • Wall mounting may be a problem where vandals may destroy the unit (in public garages, e.g.). Therefore, use steel fixing elements instead of the dowels and screws included in the delivery. •...
  • Page 38 Use of Cable Bushings ® The cable bushings included in the 2N IP Safety delivery are designed for the following cables: • Big bushing: for two cables of the diameter of 5–6 mm (UTP cable), or, upon insert replacement, for one thick cable/tube of the diameter of up to 14 mm. ...
  • Page 39 Installation manual 2N® IP Safety  • Even a LAN cable including the RJ-45 connector can go through the big bushing. See below for instructions. How to Pull a RJ-45 Terminated Cable through a Bushing 1. Unscrew the big bushing nut completely.
  • Page 40 Installation manual 2N® IP Safety 4. Replace the cover onto the sealing. 5. Pull the cable connector though the bushing body into the intercom and clip it into the motherboard connector. 6. Move the sealing including the cover along the cable as far as the bushing body, or add a plug if necessary.
  • Page 41 Installation manual 2N® IP Safety 41 /  82...

  • Page 42: Electric Installation

    Installation manual 2N® IP Safety 2.3 Electric Installation ®   This subsection describes how to connect 2N IP Safety into your Local Area Network (LAN) and how to connect supply voltage and the electric lock. • PCB Connectors • LAN Connection • External Power Supply Connection •...
  • Page 43 Installation manual 2N® IP Safety PCB Connectors ®  Picture shows the lay-out of connectors on the 2N IP Safety  printed circuit board (PCB). Cables, accessories and other system components are connected to connectors X1 through X22. ®  IP Safety Connectors, PCB Version 555v2...
  • Page 44 Installation manual 2N® IP Safety ®  IP Safety Connectors, PCB Version 555v3 44 /  82...
  • Page 45 Installation manual 2N® IP Safety ®  IP Safety Connectors, PCB Version 555v5 Description of Connectors: • X1 – Loudspeaker • X4 – Camera module • X5 – Button 1 • SW1 – Reset button (555v3 and higher versions only) • X6 – Configuration jumpers • X7 – Induction loop output. Connector type JST SHR-02V-S.
  • Page 46 Installation manual 2N® IP Safety • X16 – Right-hand microphone • X17 – Relay NO and NC contact. Used for connection of non-critical devices only (lights, e.g.). • X18 – 12 V / 600 mA switched output • X19 – 12 V / 1 A DC power input •...
  • Page 47 We recommend the use of a shielded SSTP Ethernet cable. External Power Supply Connection ®  IP Safety  can be fed either from an external 12 V / 1 A DC power supply or from the LAN equipped with the PoE 802.3af supporting network elements.  ...
  • Page 48  Note • The delay after pressing RESET till the first light and sound signalling is set to 15– 35 s depending on the 2N IP intercom/answering unit model used. ® • 24 s is the valid value for 2N  IP Safety HW version 8.
  • Page 49 Installation manual 2N® IP Safety Static IP Address Setting Follow the instructions below to switch on the Static IP address mode (DHCP OFF): • Press and hold the RESET button. • Wait until the red and green LEDs go on simultaneously on the device and the acoustic signal ...
  • Page 50 Installation manual 2N® IP Safety   Factory Reset (PCB version 555v8 and latest) Follow the instructions below to reset the factory default values: • Press and hold the RESET button. • Wait until the red and green LEDs go on simultaneously and the acoustic signal ...
  • Page 51 Press the RESET button shortly (< 1 s) to restart the system without changing configuration.  Note • The time interval between the short press of RESET and reconnection after restart ® is 25–50 s for 2N  IP Safety depending on the HW version.   51 /  82...
  • Page 52 Installation manual 2N® IP Safety Factory Default Resetting (PCB version 555v3 and higher) For resetting device to default settings press and hold SW1 button. Wait for the first sound signalization and then release the button. If you press the button for short time device will reboot only.
  • Page 53 Installation manual 2N® IP Safety Configuration jumpers X6, PCB version 555v2: Normal operation Default setup   53 /  82...
  • Page 54 Installation manual 2N® IP Safety Grounding We recommend to ground the intercom in order to improve the static electricity resistance. For proper grounding you need a cable of the minimum cross-section of 4 mm2. Connect the cable to the connector in the bottom part of the intercom. The connector is enclosed to the delivery.
  • Page 55 Water leakage may damage the electronic part of the system. ® • Stainless steel screws are used for the 2N  IP Safety assembly. Other screws than stainless steel ones corrode soon and may aesthetically deteriorate the surrounding environment!
  • Page 56 Installation manual 2N® IP Safety  Warning When you connect a device containing a coil, such as a relay or an electromagnetic lock, it is necessary to protect the intercom against voltage peak while switching off the induction load. For this way of protection we recommend a diode 1 A / 1000 V (e.g., 1N4007, 1N5407, 1N5408) connected antiparallel to the device.

  • Page 57: Overvoltage Protection

    2N device wiring may be exposed to atmospheric effects resulting in overvoltage that may subsequently damage any devices installed outside the building, on its outer wall or roof.
  • Page 58  IPSafety Additional Switch adds two additional switches, one logical input and a ® tamper switch to the 2N  IP Safety basic unit. The purpose of the tamper switch is to signal any unauthorised opening of the intercom (to prevent a theft, e.g.). It is recommended to use the tamper switch.
  • Page 59 Installation manual 2N® IP Safety Specifications version 5: • IN2 terminals for input in passive / active mode (-30 V to +30 V DC) •  OFF = open OR UIN > 1.5 V • ON = closed contact OR UIN < 1.5 V •...
  • Page 60 Installation manual 2N® IP Safety Module settings: Refer to the Configuration Manual for details. 60 /  82...
  • Page 61 The Security Relay (Part No. 9159010) is used for enhancing security between the intercom and ®  the connected electric lock. The 2N Security Relay is designed for any 2N IP intercom model with firmware versions 1.15 and higher. It significantly enhances security of the connected electric lock as it prevents lock opening by forced intercom tampering.
  • Page 62 The 2N  Security Relay is a device installed between an intercom (outside the secured area) ®  and the electric lock (inside the secured area). The 2N Security Relay includes a relay that can only be activated if the valid opening code is received from the intercom.
  • Page 63 Installation manual 2N® IP Safety Connection: ® Connect the 2N  Security Relay to the intercom as follows: • To the intercom active output (OUT1 or OUT2 if a reader module or additional switch is connected) ® Connect the electric lock to the 2N  Security Relay output as follows: •...
  • Page 64 Configuration: ® • Connect the 2N  Security Relay to the properly set intercom switch output; refer ® to the Configuration Manual. Make sure that one LED at least on the 2N  Security Relay is on or blinking. ® • Press and hold the 2N  Security Relay Reset button for 5 seconds to put the device in the programming mode (both the red and green LEDs are blinking).
  • Page 65 Installation manual 2N® IP Safety  ® • FAQ: Security Relay – what it is and how to use it with 2N IP intercom? Connection:  Video Tutorial: Security Relay Installation and Configuration Sorry, the widget is not supported in this export.
  • Page 66 You can place the mated A and B connectors into the 2N IP intercom cover. The connectors help you connect stripped cables. Open the connector by pushing a thin screwdriver onto the white spots at its front and close the connector by sliding the movable part through a side gap.
  • Page 67 Installation manual 2N® IP Safety Specifications: • Supply voltage: 8 – 18VDC • Supply current at 12 V supply: • 1 Ω load, full power output; 1.4 A, sine wave signal; 1 A, pink noise signal • 8 Ω load, half power output; 550 mA, sine wave signal; 400 mA, pink noise signal •...

  • Page 68: Function And Use

    You have to know the IP address of your device to log in to the integrated web server. By ® default, 2N  IP Safety is switched into the dynamic IP address mode, i.e. it obtains the IP address automatically if a properly set DHCP server is available in your LAN. If no such DHCP ®...
  • Page 69 Up to 2 s intervals are allowed between the presses. Switching between Static and Dynamic IP Address ® • Connect 2N  IP Safety to the power supply (or, disconnect and reconnect it if already connected). • Wait for the first sound signal  •...

  • Page 70: Maintenance

    Installation manual 2N® IP Safety  Caution • The 15 times 1 sequence must be entered within 30 seconds after the first sound signal for security reasons. The inter-digit delay may be 2 s at most. The static IP address mode will be switched into the dynamic IP address mode and vice versa upon restart.

  • Page 71: Downloads

    Installation manual 2N® IP Safety  ® • The 2N IP Safety models of Part Nos. 9152101W, 9152102W and 9152101MW may be cleaned with WAP high pressure washers. Future Programming Changes For necessary steps refer to the preceding subsections. Keep the following for future changes: •...

  • Page 72: Technical Parameters

    Installation manual 2N® IP Safety 4. Technical Parameters Signalling protocol • SIP (UDP, TCP, TLS)  Buttons • Button design: Industrial waterproof, stainless steel, vandal resistant pushbutton, blue backlit • Count of buttons: 1 (2 on request) • Numerical keypad: (on request) Audio • Microphone: 2 integrated microphones •...
  • Page 73 Installation manual 2N® IP Safety Bandwidth  • Audio codecs • PCMA, PCMU – 64 kbps (with 85.6 kbps headers) • G.729 – 16 kbps (with 29.6 kbps headers) • G.722 – 64 kbps (with 85.6 kbps headers) • L16 / 16 kHz – 256 kbps (with 277.6 kbps headers) •...
  • Page 74 Installation manual 2N® IP Safety Interface • Power supply: 12 V ±15 % / 2 A DC or PoE • PoE: PoE 802.3af (Class 0–12.95 W) • LAN: 10/100BASE-TX s Auto-MDIX, RJ-45 • Recommended cabling: Cat-5e or higher • Supported protocols: SIP2.0, DHCP opt. 66, SMTP, 802.1x, RTSP, RTP, TFTP, HTTP, HTTPS, Syslog, ONVIF •...

  • Page 75: General Drawings

    Installation manual 2N® IP Safety 4.1 General drawings Surface mounting 75 /  82...
  • Page 76 Installation manual 2N® IP Safety Flush mounting Plasterboard mounting  Flush mounting with box   76 /  82...

  • Page 77: Supplementary Information

    5.1 Troubleshooting For the most frequently asked questions refer to faq.2n.cz. 5.2 Directives, Laws and Regulations ® IP Safety conforms to the following directives and regulations: • 2014/35/EU for electrical equipment designed for use within certain voltage limits • 2014/30/EU for electromagnetic compatibility •...
  • Page 78 Installation manual 2N® IP Safety Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.   78 /  82...

  • Page 79: General Instructions And Cautions

    / device in contradiction to the manufacturer’s instructions, guidelines or recommendations or in conjunction with unsuitable products / devices of other suppliers, the customer agrees that the 2N TELEKOMUNIKACE a.s. company shall not be held liable for any functionality limitation of such a product or any damage, loss or injury related to this potential functionality limitation.
  • Page 80 Installation manual 2N® IP Safety Moreover, the manufacturer shall not be liable for any damage or destruction of the product incurred as a result of misplacement, incompetent installation and/or undue operation and use of the product in contradiction herewith. The manufacturer assumes no responsibility for any malfunction, damage or destruction of the product caused by incompetent replacement of parts or due to the use of reproduction parts or components.
  • Page 81 Installation manual 2N® IP Safety friendly disposal. The dealer or manufacturer shall take the product back free of charge and without requiring another purchase. Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either.
