  • Page 1     Installation manual 2N® IP Solo             v.2.18 www.2n.com...

  • Page 2: Table Of Contents

    Installation manual 2N® IP Solo Content: • 1. Product Overview • 1.1 Components and Associated Products • 1.2 Terms and Symbols • 2. Description and Installation • 2.1 Before You Start • 2.2 Mechanical Installation • 2.2.1 Main Unit Mounting •...

  • Page 3: Product Overview

    1.2 Terms and Symbols Basic Features ®  IP Solo is an elegant and reliable intercom equipped with lots of useful functions. Thanks to SIP support and compatibility with major brands of PBX manufacturers, it can benefit from using ® VoIP networks. 2N  IP Solo can be used as a door or special purpose intercom for office...

  • Page 4: Components And Associated Products

    Installation manual 2N® IP Solo • Sensitive microphone and loud speaker • Both-way audio communication – acoustic echo cancellation • Integrated colour HD camera with wide-angle lense and hidden night vision • Integrated switches of electric locks with wide setting options •...
  • Page 5 Installation manual 2N® IP Solo • Main unit • Flush mount 2N Part No. 9155301F • Cameraless version Axis Part No. 02205-001 • Main unit • Flush mount 2N Part • HD camera No. 9155301CBF Axis Part No. 01303-001 • Main unit •...
  • Page 6 Installation manual 2N® IP Solo • Main unit • Surface mount 2N Part No. 9155301CS • HD camera Axis Part No. 01301-001 • Main unit • Surface mount 2N Part No. 9155301S • Cameraless version Axis part No. 02203-001 • Main unit •...
  • Page 7 Installation manual 2N® IP Solo • Main unit • Surface mount 2N Part No. 9155301BS • Cameraless version Axis Part No. 02202-001 Mounting Accessories • Flush mounting box  • Designed for flush or plasterboard mounting. 2N Part No. 9155017 Axis Part No.
  • Page 8 IP Solo onto a glass surface. Axis Part No. 02078-001 Choose the proper frame and, if necessary, mounting box type depending on your ® ® particular 2N  IP Solo installation needs.2N  IP Solo is designed for outdoor applications and requires no additional roof. 8 /  74...
  • Page 9 The elegant internal touch panel, 2N Indoor Touch 2.0, is 2N Part No. 91378375 suitable for all 2N IP intercoms. On the panel’s display not Axis Part No. only can you find out who is at the door, but also start a...
  • Page 10 The elegant internal touch panel, 2N Indoor Touch 2.0, is 2N Part. No. suitable for all 2N IP intercoms. On the panel’s display not 91378375WH only can you find out who is at the door, but also start a Axis Part No.
  • Page 11 Installation manual 2N® IP Solo ® •  IP Handset • answering unit 2N Part No. Axis Part • white color 1120101W 02518-001 ® •  IP Handset • answering unit 2N Part Axis Part • black color 1120101B 02519-001   11 /  74...
  • Page 12 Installation manual 2N® IP Solo IP Phones • 2N® IP Phone D7A  • simple operation 2N Part No. 1120102 • HD quality video calls Axis Part No. 02660-001 • A display-equipped extender EXP50 (Part No. 91378363) can be added to the phone delivery to make up to 60 speed dialings.
  • Page 13 Installation manual 2N® IP Solo Part No. 11202101-L • Mini electronic doorstrike series 5 – long • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular • long sheet metal front cover version (250 mm) •...
  • Page 14 Installation manual 2N® IP Solo Part No. 11202103 • Mini electronic doorstrike series 5 – with mechanical blocking • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular •...
  • Page 15 Installation manual 2N® IP Solo Part No. 11202104-L • Mini electronic doorstrike series 5 – door signaling, long • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular •...
  • Page 16 Electromechanical lock SAM 7255 • 72/55 self-locking lock with panic function • A key is necessary for door opening from the outside (or an electric pulse from a connected 2N IP intercom / reader). • convenient solution for emergency exits 16 /  74...
  • Page 17 Electromechanical lock SAM 7255 with monitoring • 72/55 self-locking lock with panic function • A key is necessary for door opening from the outside (or an electric pulse from a connected 2N IP intercom / reader). • convenient solution for emergency exits Part No. 11202202 •...
  • Page 18 Installation manual 2N® IP Solo Part No. 11202301 • Cable protector FX290 • Provides secure passage and protection of the supply cable between the door frame and the door leaf. • 290 mm length Part No. 11202302 • Cable protector FX510 •...
  • Page 19 Installation manual 2N® IP Solo Part No. 11202304 • Cable protector FX500G • Provides secure passage and protection of the supply cable between the door frame and the door leaf. • 640 mm length Part No. 11202107 • Maglock MEX100 •...
  • Page 20 / left doors • in / out opening versions  • FAQ: Electric locks – Difference between locks in 2N IP intercoms accesories Power Supply • PoE injetor – with EU cable • PoE injector – with US cable Part Numbers: •...
  • Page 21 Installation manual 2N® IP Solo • Stabilised 12 V / 2 A power supply needs to be used where no PoE is available. Part No. 91341481E Axis Part No. 02520-001 • 12 V transformer • For 230 V mains voltage. Part No. 932928 •...
  • Page 22 • Standalone IP device which can be controlled by HTTP 2N Part No.  9137410E commands sent by the 2N IP intercom, which can thus Axis Part No. 01397-001 control devices via an unlimited distance. • External IP Relay – 4 outputs, PoE •...
  • Page 23 Installation manual 2N® IP Solo Sensors and Switches • Exit button • A logic input connecting button for door opening inside a Part No. 9159013 building. Axis Part No. 02523-001 • Magnetic door contact • Designed for door installation to indicate the door opening 2N Part No.
  • Page 24 Includes Enhanced Video, Enhanced Integration and Lift 2N Part No. 9137909 Control licenses • InformaCast 2N Part No. 9137910 Axis Part No. 01381-001  • Refer to the Configuration Manual for 2N IP intercoms, Subs. 3.2 Function Licensing for details. 24 /  74...

  • Page 25: Terms And Symbols

    Installation manual 2N® IP Solo 1.2 Terms and Symbols The following symbols and pictograms are used in the manual:  Safety • Always abide by this information to prevent persons from injury.  Warning • Always abide by this information to prevent damage to the device.

  • Page 26: Description And Installation

    • 2.4 Extending Module Connection • 2.5 Completion 2.1 Before You Start Product Completeness Check ® Before you start please check whether the contents of the package of your new 2N  IP Solo complies with the following list. ® • 1x 2N  IP Solo Surface installation •...
  • Page 27 • plaster, mounting glue, mounting foam or mortar as necessary ® • IP Solo, flush mounting boxes (Part No. 9155017) Flush mounting – plasterboard What you need for mounting: • a properly cut hole as instructed in the box package ®...
  • Page 28 • glass surface What you need for mounting: ® •  IP Solo, glass mounting backplate (Part No. 9155074)  Caution • The warranty does not apply to the product defects and failures arisen as a result of improper mounting (in contradiction herewith). The manufacturer is neither liable for damage caused by theft within an area that is accessible after the attached electric lock is switched.
  • Page 29 Installation manual 2N® IP Solo General Mounting Principles  • Select flush mounting where possible to make your product elegant looking, more vandal resistant and more secure. • You are advised to buy the flush mounting boxes in advance and commission your building company to do the masonry for you.
  • Page 30 (especially onto the sealing surface). ® • Never turn 2N IP Solo to align the box assembly after mounting. Make sure that the flush mounting boxes have been installed accurately. • Check the plasterboard wall and room interior pressure values. If the difference between the values is too great (as a result, e.g., of overpressure ventilation),...

  • Page 31: Main Unit Mounting

    Installation manual 2N® IP Solo  Safety • Eliminate the risk of personal injury! Surface mounting is not recommended for narrow passages or places where people's attention is distracted by something else. The manufacturer shall not be liable for injuries in such cases! ...
  • Page 32 Installation manual 2N® IP Solo 2.2.1 Main Unit Mounting Flush mounting – classic bricks and plasterboard 32 /  74...
  • Page 33 Installation manual 2N® IP Solo 33 /  74...
  • Page 34 Installation manual 2N® IP Solo Wall (surface) mounting 34 /  74...
  • Page 35 Installation manual 2N® IP Solo 35 /  74...
  • Page 36 Installation manual 2N® IP Solo Wall (surface) mounting using backplate 36 /  74...
  • Page 37 Installation manual 2N® IP Solo 37 /  74...

  • Page 38: Electric Installation

    Main Unit Power Supply Connection ®  IP Solo can be powered either from an external 12 V / 2 A DC source or directly from the LAN equipped with PoE 802.3af supporting network elements. External power supply Use a 12 V ±15 % SELV supply dimensioned to the minimum current consumption of 2 A (Part No.
  • Page 39 LAN Connection ®  IP Solo is connected to the Local Area Network (LAN) via the UTP/STP cable (Cat 5e or higher) terminated with an RJ-45 (LAN) connector. As the device is equipped with the Auto-MDIX function, both the straight and crossed cable can be used.
  • Page 40 Installation manual 2N® IP Solo Basic Unit with Camera (HW version 3) Basic Unit without Camera (HW version 3) Relay 1 OUT 1 Audio 2.556 *power output of 2.556 *power output of 2 W / 4 ohm 2 W / 4 ohm Total 1.030...
  • Page 41 Installation manual 2N® IP Solo Main Unit Connector Configuration Legend LAN (PoE) LAN (PoE according to 802.1af) connector IN1 terminals for input in passive/ active mode  (−30 V to +30 V      OFF = open OR U > 1.5 V     ...
  • Page 42 Installation manual 2N® IP Solo  • Output wiring diagram for Relay terminals   Wiring diagram for the controlled device’s electric circuit closing   Wiring diagram for the controlled device’s electric circuit opening 42 /  74...
  • Page 43 Installation manual 2N® IP Solo  • Wiring Diagram of IN1 connector in active mode • Wiring Diagram of IN1 connector in passive mode 43 /  74...
  • Page 44  Note • The delay after pressing RESET till the first light and sound signalling is set to 15– 35 s depending on the 2N IP intercom/answering unit model used. ® • 18 s is the valid value for 2N  IP Solo.
  • Page 45 Installation manual 2N® IP Solo • Wait until the red LED goes off and the acoustic signal   can be heard (approx. for another 3 s). • Release the RESET button. The following network parameters will be set after restart: • IP address: 192.168.1.100 •...
  • Page 46 Installation manual 2N® IP Solo Factory Reset Follow the instructions below to reset the factory default values: • Press and hold the RESET button. • Wait until the red and green LEDs go on simultaneously and the acoustic signal   can be heard (approx.
  • Page 47 Installation manual 2N® IP Solo  Caution • In case of resetting the factory default settings on a device with a version of firmware 2.18 or higher it is necessary to reprogram the ®  Security Relay using the instructions from section 2.4.
  • Page 48 Installation manual 2N® IP Solo  Warning When you connect a device containing a coil, such as a relay or an electromagnetic lock, it is necessary to protect the intercom against voltage peak while switching off the induction load. For this way of protection we recommend a diode 1 A / 1000 V (e.g., 1N4007, 1N5407, 1N5408) connected antiparallel to the device.
  • Page 49 Installation manual 2N® IP Solo Main Unit LED Pictograms Main Unit LED Pictogram Layout 49 /  74...

  • Page 50: Overvoltage Protection

    2N device wiring may be exposed to atmospheric effects resulting in overvoltage that may subsequently damage any devices installed outside the building, on its outer wall or roof.

  • Page 51: Extending Module Connection

     IP Security Relay (Part No. 9159010) is used for enhancing security between the ® intercom and the connected electric lock. The 2N  IP Intercom Security Relay is designed for any 2N IP intercom model with firmware versions 1.15 and higher. It significantly enhances security of the connected electric lock as it prevents lock opening by forced intercom tampering. Function: ®...
  • Page 52 Installation manual 2N® IP Solo Installation: ® Install the 2N  IP Intercom Security Relay onto a two-wire cable between the intercom and the electric lock inside the area to be secured (typically behind the door). The device is powered and controlled via this two-wire cable and so can be added to an existing installation.
  • Page 53 2.18 or higher it is necessary to reprogram the ®  IP Intercom Security Relay using the instructions above.  ® • FAQ: IP Intercom Security Relay – what is it and how to use it with 2N IP intercom? 53 /  74...

  • Page 54: Completion

    Installation manual 2N® IP Solo Connection:  Video Tutorial: Security Relay Installation and Configuration Sorry, the widget is not supported in this export. But you can reach it using the following URL: https://www.youtube.com/watch?v=ardukvQzw5A 2.5 Completion Installation Completion Check the connection of all wires and the RJ-45 plug to the board connector.
  • Page 55 Installation manual 2N® IP Solo Nametag Placing Every intercom package includes a piece of transparent foil, which can be laser printed. Cut the printed foil and insert the nametags in the buttons. Nametag dimensions for button:  • 1 button: 52.0 (W) x 15.2 (H) mm (dimensional tolerance: +0; -0.5 mm) ...
  • Page 56 Installation manual 2N® IP Solo  Caution • Improper mounting may deteriorate the intercom waterproofness and water may damage the electronic part. • Make sure that all holes are filled with some waterproof material – the top part, around the cables and the screws.

  • Page 57: Function And Use

    You have to know your intercom IP address to log in to the integrated web server. Upon ® purchase, 2N IP Solo is set to the dynamic IP address mode – it retrieves the IP address automatically if there is a properly configured DHCP server in the LAN. If no DHCP is available, ®...
  • Page 58 Installation manual 2N® IP Solo IP Address Retrieval ® Take the following steps to retrieve the 2N IP Solo IP address: ® • Connect (or, if connected, disconnect and reconnect) 2N IP Solo to the power supply. • Wait for the second sound signal  •...
  • Page 59 Take the following steps to switch the dynamic and static IP address mode in  ® IP Solo: ® • Connect (or, if connected, disconnect and reconnect) 2N IP Solo to the power supply. • Wait for the first sound signal  • Press the quick dial button on the main unit 15 times.

  • Page 60: Intercom Control As Viewed By External User

    Door Opening (Switch Activation) by Code ®  IP Solo is equipped with a door unlocking switch. Enter the valid code (refer to the Intercom Configuration / Hardware / Switches subsection of Configuration Manual) using your phone keypad to activate this switch.

  • Page 61: Maintenance

    Installation manual 2N® IP Solo Procedure:  • Enter the switch 1 or 2 activating code using your phone keypad and press   for confirmation. Confirmation is unnecessary if the Lock code without confirmation is enabled, refer to the  Intercom Configuration / Hardware / Switches / Advanced subsection of Configuration Manual.

  • Page 62: Downloads

    The manufacturer reserves the right to modify the product in order to improve its qualities. ® • IP Solo contains no environmentally harmful components. When the product's service life is exhausted and you would like to dispose of it please do so in accordance with applicable legal regulations. 3.5 Downloads...

  • Page 63: Technical Parameters

    Installation manual 2N® IP Solo 4. Technical Parameters Signalling protocol • SIP (UDP, TCP, TLS) Buttons • Button design: white-backlit transparent button with replaceable nametags • Button count: 1 Audio • Microphone: 1 integrated microphone • Amplifier: 2 W (class D) amplifier • Speaker: 2 W / 8 Ω...
  • Page 64 Installation manual 2N® IP Solo Camera • Sensor: 1/3'' colour CMOS • JPEG resolution: up to 1280 (H) x 960 (V) • Video resolution: 640 (H) x 480 (V) • Frame rate: up to 30 snapshots/s • Sensor sensitivity: 5.6 V/lux-sec (550 nm) • View angle: 128 ° (H), 95 ° (V), 134 ° (D) •...
  • Page 65 Installation manual 2N® IP Solo Bandwidth  • Audio codecs • PCMA, PCMU – 64 kbps (with 85.6 kbps headers) • G.729 – 16 kbps (with 29.6 kbps headers) • G.722 – 64 kbps (with 85.6 kbps headers) • L16 / 16 kHz – 256 kbps (with 277.6 kbps headers) •...
  • Page 66 Installation manual 2N® IP Solo Mechanical properties • Cover: robust zinc casting with surface finish (minor surface shade nuances are acceptable) • 91550XX – NICKEL • Material - Zamak 410 - Zn95Al4Cu1 • Surface treatment - Zn/Cu20/Ni25b max. 80 µm • 91550XXB – BLACK  ...

  • Page 67: General Drawings

    Installation manual 2N® IP Solo 4.1 General drawings Surface mounting 67 /  74...
  • Page 68 Installation manual 2N® IP Solo  Flush mounting 68 /  74...

  • Page 69: Supplementary Information

    5.1 Troubleshooting For the most frequently asked questions refer to faq.2n.cz. 5.2 Directives, Laws and Regulations ® IP Solo conforms to the following directives and regulations: • 2014/35/EU for electrical equipment designed for use within certain voltage limits • 2014/30/EU for electromagnetic compatibility •...
  • Page 70 Installation manual 2N® IP Solo Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.   70 /  74...

  • Page 71: General Instructions And Cautions

    / device in contradiction to the manufacturer’s instructions, guidelines or recommendations or in conjunction with unsuitable products / devices of other suppliers, the customer agrees that the 2N TELEKOMUNIKACE a.s. company shall not be held liable for any functionality limitation of such a product or any damage, loss or injury related to this potential functionality limitation.
  • Page 72 Installation manual 2N® IP Solo Moreover, the manufacturer shall not be liable for any damage or destruction of the product incurred as a result of misplacement, incompetent installation and/or undue operation and use of the product in contradiction herewith. The manufacturer assumes no responsibility for any malfunction, damage or destruction of the product caused by incompetent replacement of parts or due to the use of reproduction parts or components.
  • Page 73 Installation manual 2N® IP Solo friendly disposal. The dealer or manufacturer shall take the product back free of charge and without requiring another purchase. Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either.
  • Page 74 Installation manual 2N® IP Solo 74 /  74...
