2N IP Style Installation Manual page 71

RELAY1 RELAY1 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
RELAY2 RELAY2 terminals with accessible 30 V / 1 A AC/DC NO/NC contact
IN1 IN1 terminals for input in passive / active mode (
OFF = open contact or U
ON = closed contact or U
IN2 IN2 terminals for input in passive / active mode (
OFF = open contact or U
ON = closed contact or U
TAMPER Tamper switch (9155038) input
2N TELEKOMUNIKACE a.s., www.2n.cz
> 1.5 V
IN
< 1.5 V
IN
> 1.5 V
IN
< 1.5 V
IN
− 30 V to +30 V DC)
− 30 V to +30 V DC)
71/105
