Basic Features 2N IP Style is an elegant and reliable intercom equipped with lots of useful functions. Thanks to SIP support and compatibility with major brands of PBX manufacturers, it can benefit from using VoIP networks.
Page 6 Product Description • bidirectional communication – acoustic echo cancellation, • integrated color HD camera with a wide-angle lens and night vision • numeric touch keypad, • integrated electronic lock switches with wide setting options, • integrated 125 kHz and 13.56 MHz (optionally secured) RFID card reader, •...
Page 7: Product Versions
Includes an internal 125 kHz card reader and 13.56 MHz secure card reader. Accessories Accessories for Installation 2N IP Style is designed for both outdoor and indoor applications and requires no additional roof. Choose the proper frame and, if necessary, a mounting box depending on your particular installation needs.
Page 8: Extenders
Product Description Part No. 9155050/9155054/9155055 Axis Part No. 01267-001/01268-001/01269-001 1/3/5 m interconnecting cable Interconnection cable for distant module installation. Only one interconnecting cable is allowed per installation. The maximum bus length is 7 m. Part No. 9157002 Axis Part No. 02941-001 Surface mounting chassis The flush mounting box is used for connection and storage of cables below the device.
Page 9 • NXP HiTag2 Part No. 91550942 Axis Part No. 02139-001 2N IP Verso 13.56 MHz, NFC ready It provides access control via contactless cards or key fobs. The mod- ule supports the following 13.56 MHz cards or other carriers: Supported RFID cards 13.56 MHz:...
Page 10 Part No. 9155086 Axis Part No. 01712-001 2N IP Verso RFID – 125 kHz, 13.56 MHz, NFC It provides access control via contactless cards or key fobs. The mod- ule supports the following 13.56 MHz cards or other carriers: Compatible with firmware version 2.13 and higher.
Page 11 Part No. 91550945-S Axis Part No. 02444-001 2N IP Verso Bluetooth & RFID – 125 kHz, 13.56 MHz, NFC A combined Bluetooth – card reader module helps you control access using an access code, Mobile Key in your smartphone or an access card.
Page 12 Part No. 91550947 Axis Part No. 02781-001 2N IP Verso Touch keypad & Bluetooth & RFID - 125 kHz, 13.56 MHz, NFC A combined touch keypad – Bluetooth – card reader module helps you control access using an access code, Mobile Key in your smartphone or an access card.
Page 13 Part No. 91550947-S Axis Part No. 02782-001 2N IP Verso Touch keypad & Bluetooth & RFID - 125 kHz, secured 13.56 MHz, NFC A combined touch keypad – Bluetooth – card reader module helps you control access using an access code, Mobile Key in your smartphone or an access card.
Page 14 Part No. 91550371 Axis Part No. 02577-001 OSDP Module The OSDP module provides OSDP communication with a connected OSDP device (control panel, door controller) and 2N IP Style (placed outside). The module is installed under another module, i.e. needs no separate position.
Page 15: Power Supply
Product Description Power Supply Part No. 9159052 Axis Part No. 01393-001 12 V / 1 A power supply for 2N Induction Loop The external induction loop power supply has 230 V AC input voltage and 12 V DC output voltage. Licenses Part No.
Page 16 The departure button is connected to the device logic input for opening the door from inside the building. Part No. 9157003 Axis Part No. 02743-001 Protective glass for 2N IP Style touch screen The protective hardened glass with 9H and IK08 ratings has an active hygienic protection. Part No. 9159012 Axis Part No.
Page 17 Product Description Part No. 9134165E Axis Part No. 01395-001 RFID chip card EM, 125 Hz RFID chip card, type EM4100, 125 kHz. Part No. 9134166E Axis Part No. 01396-001 RFID chip fob EM, 125 Hz RFID chip fob, type EM4100, 125 kHz. Part No.
Page 18 • FeliCa (Standard, Lite) • ST SR (SR, SRI, SRIX) • Mobile Key The device can also read the 13.56 MHz 2N PICard RFID cards. Part No. 9137424E Axis Part No. 01527-001 External secured RFID reader, 13.56 MHz + 125 kHz, NFC/HCE External secured RFID card reader connectable to a PC via a USB interface.
Page 19 IP de- vice. You do not have to configure anything, all you need is one 2N 2Wire unit at each end of the cable and a power supply connected to at least one of these units.
Page 20: Package Completeness Check
Certificate of ownership Quick Start manual Module / Frame Package Completeness Check The package of modules for 2N IP Style includes: 3 x 8 mm stainless steel thread-forming lens head screw for plastic CAUTION If spare accessories other than the specified types are used, the device warranty might...
Page 21: Installation
Mechanical Installation Installation Conditions Make sure that the following 2N IP Style installation conditions are met. • There must be enough space for the device installation. • Make sure that the dowel holes have the required diameter. If the diameters are too large, the dowels may get loose! Use the mounting glue to secure the dowels if necessary.
Page 22: Installation Tips
Viewing angle 144° (H), 126° (V) Flush Mounting The flush mounting box allows you to place cables in the wall below 2N IP Style and mount the device. What you need for mounting: • 2N IP Style • Flush mounting box (Part No. 9157001)
Page 23: Box Installation
Installation Box Installation...
Page 24: Main Unit Installation
Installation Make a hole of the size of 352 (h) x 167 (w) x 45 (d) mm for the mounting box installation. Remove the selected blank for cabling. Thread the cables through the selected box hole and put the mounting box in the pre-prepared hole.
Page 25 Installation Unscrew the connector cover on the back of the device. Thread all of the cables with no connectors (terminals or end pieces, etc.) through the bushing on the inside of the connector cover. After threading the cables through the bushing, fit the required end pieces.
Page 26: Surface Installation
Lock the position by tightening the two screws inside the device using an Allen key. Surface Installation What you need for mounting: • 2N IP Style • surface mounting chassis (Part No. 9157002) Download the drilling template...
Page 27: Chassis Installation
Installation Chassis Installation Drill chassis anchoring holes on a proper place. Use the chassis itself as a template to maintain the horizontal level and carry the cabling at the bottom edge of the cable hole. The recommended length of the accessible cables is 35 cm. Insert the dowels in the holes drilled and use the screws to anchor the chassis.
Page 28 Installation Unscrew the connector cover on the back of the device. Thread all of the cables with no connectors (terminals or end pieces, etc.) through the bushing on the inside of the connector cover. After threading the cables through the bushing, fit the required end pieces.
Page 29: Electric Installation
• Make sure that the external power supply meets the power supply class 2 (PS2/LPS) . PoE Supply 2N IP Style is compatible with the PoE 802.3af technology (Class 0, max. 12.95 W) and can be supplied directly from the LAN via compatible network elements. If your LAN does not support this technology, insert a PoE injector (01403-001/02445-001), between 2N IP Style and the nearest network element.
Page 30: Combined Power Supply
Current consumption [A] Available power output [W] Combined Power Supply 2N IP Stylecan be fed from an external power supply and PoE at the same time. In this configuration, the maximum power for the is available. WARNING • In case the external power supply is disconnected / fails during the combined external / PoE feeding, the device will get restarted.
Page 31 Installation Main Unit Max Power Overview Main unit Max consumption Max consumption Max consump- tion mA (from 12V W (from 12V sup- supply) ply) W (z PoE+) At relax 6.06 7.13 Restart 9.88 Infrared light (100%) 2.12 Display backlight intensity (100%) 5.65 Audio (100 %) 1420...
Page 32: Device Connectors
Installation Device Connectors Main unit connector wiring...
Page 33 Installation Name Description LAN BOOT BUT- LAN Connection Restart Button SD CARD SD card slot CONTROL BUT- Factory reset button POWER LED Device status LED LAN LED LAN connection status LED VBUS Bus connector SHIELD Grounding terminal CAUTION We recommend that a grounding cable of the cross-section of 1.5 mm is used.
Page 34: Available Switches
Installation Name Description Tamper Switch Switch detecting unauthorized device opening Available switches Location Name Description Main unit RELAY Passive switch: • switching and expandable contact • max. 30 V / 1 A AC/DC • only used to connect non-critical devices (e.g. lights) Active switch output: •...
Page 35 Relay Terminal Wiring Diagrams It is possible to connect a device to the 2N IP Style relay terminals to be controlled by this relay, e.g. an electric/electromechanical door lock. The elements are designated as follows in the diagrams below:...
Page 36 Installation Wiring diagram for closing the electric circuit of the controlled device...
Page 37 Installation Wiring diagram for opening the electric circuit of the controlled device Connection of IN1 inputs (or IN2) It is possible to connect an external button, e.g. a departure button or door open sensor, to the IN1 or IN2 terminals of device2N IP Style. The following wiring diagrams apply both to IN1 and IN2.
Page 38: Lan Connection
LAN Connection 2N IP Style is connected to the LAN by inserting a SSTP cable (category Cat-5e or higher) in the dedicated LAN connector on the device. As the device is equipped with the Auto-MDIX function, you can use either the straight or crossed cable version.
Page 39 Installation Examples of Overvoltage Protection Installation Overvoltage protection installation diagram for a device installed on the building facade and cables outside the building...
Page 40 Installation Overvoltage protection installation diagram for a device installed on the building facade and cables inside the building...
Page 41 Installation Overvoltage protection installation diagram for a device and cables installed outside the building...
Page 42: Main And Extending Modules
Main and Extending Modules Main and Extending Modules 2N IP Style can be interconnected with the following modules: • 125 kHz RFID card reader (p. 43) • 13.56 MHz NFC RFID card reader (p. 44) • Secured 13.56 MHz, NFC RFID card reader (p. 44) •...
Page 43: Module Power Supply
Combined Module Specifications Induction Loop Module The Induction Loop module (9155041, 01263-001) on 2N IP Style is used for transmitting audio signals via the magnetic field directly into the hearing aids. Features • The module contains two bus connectors for the 2N IP Style bus.
Page 44: 13.56 Mhz, Nfc Rfid Card Reader Module
& touch display installation. Features • The module contains two bus connectors for the 2N IP Style bus. • These two connectors are fully interchangeable and can be used either as inputs from the main unit or outputs to other modules.
Page 45: Biometric Fingerprint Reader Module
Features • The module contains two bus connectors for the 2N IP Style bus. • These two connectors are fully interchangeable and can be used either as inputs from the main unit or outputs to other modules.
Page 46 Main and Extending Modules Features • The module contains two bus connectors for the 2N IP Style bus. • These two connectors are fully interchangeable and can be used either as inputs from the main unit or outputs to other modules.
Page 47: Wiegand Module
Wiegand Module The Wiegand module (9155037, 01259-001) is used for connecting an external Wiegand device (RFID card reader, fingerprint/biometric data scanner) and/or connecting 2N IP Style to an external security exchange. Features • The module contains two bus connectors for the 2N IP Style bus.
Page 48 Main and Extending Modules Reader helps connect an external Wiegand-supporting reader. The reader sends the device card ID. The Control Panel is used for connection to the security PBX / access system to which the device sends the card ID information. The module contains two BUS connectors for device bus connection.
Page 49 Main and Extending Modules Reader , W1 Isolated 2-wire WIEGAND IN Isolated open LED OUT switched against GND (up to 24 V / 50 Control Panel (5 to 15 V DC) for WIEGAND OUT power supply Isolated 2-wire WIEGAND OUT , GND (nega- Isolated input for open LED IN, input activated by GND...
Page 50: Osdp Module
5 V power supply OSDP Module The OSDP module (91550371, 02577-001) of 2N IP Style provides OSDP communication between a connected OSDP device (control panel, door controller) and the device. The OSDP module provides secure sending of such access data as the access card ID or PIN code.
Page 51 The module also includes: • Isolated OSDP bus • Power and pairing mode signaling LED • Tamper Switch (9155038, 01260-001) input Connectors and Installation All the inputs and outputs are galvanically isolated from 2N IP Style with the insulation strength of 1500 V...
Page 52 The module is installed under another module, i.e. needs no separate position. Having connected the OSDP module to 2N IP Style via the VBUS, connect the OSDP device to the module. The OSDP module uses the RS-485 bus for the interface.
Page 53: Tamper Switch Module
Enter the OSDP address between 0 and 126 to set the OSDP module address on the OSDP line. Set the communication rate in accordance with the requirements of the device to be connected. Enter your own encryption key into 2N IP Style and the opponent’s device to ensure encrypted commu- nication.
Page 54 Main and Extending Modules Jumpers are used for interconnecting the Tamper Switch pins with the I/O / OSDP / Wiegand module.
Page 55: Security Relay
Main and Extending Modules Security Relay The Security Relay (9159010, 01386-001) is used for enhancing security between 2N IP Style and the connected electric lock. The Security Relay significantly enhances security of the connected electric lock by preventing unlocking due to device tampering.
Page 56 The Security Relay is designed with holes for surface anchoring. It is recommended that a screw of the diameter of 3 mm with a lens head of the diameter of 6 mm is used. Using a countersunk head may cause irreversible damage to the plastic cover! 2N IP Style Door lock Departure button...
Page 57: Status Signaling
• to the passive output in series with the external power supply The Security Relay also supports the Departure button connected to the ‘PB’ and ‘– 2N IP intercom’ terminals. Once the Departure button is pressed, the output is activated for 5 seconds.
Page 58: Brief Guidelines
Device Configuration Interface Access 2N IP Style is configured via the web configuration interface. You need to know the IP address or domain name of the device for access. Make sure that the device is connected to the local IP network and powered.
Page 59: Configuration Via Hardware
Enter the login data. The default login data are: Username: Admin Password: 2n It is necessary to change the password immediately upon the first login. After login using the default password, the access to the web configuration interface functions is limited.
Page 60: Ip Address Retrieval
• Use the freely accessible 2N Network Scanner. • Display information on the device display. IP Address Retrieval Using 2N Network Scanner The application helps you find the IP addresses of all the 2N devices in the LAN. Download 2N Network Scanner from the 2N.com website.
Page 61 In that case, click Refresh to find the device again and check whether multicast is enabled in your network. • Double click the selected row in the 2N Network Scanner list to access the device web interface easily. • To change the device IP address, select Config and enter the required static IP address or activate DHCP.
Page 62: Ip Address Retrieval Using Device Display
FW version. The 2N IP Style firmware also includes the up-to-date touch display controller. The display touch layer show- ing the ongoing upgrade notification does not respond during the upgrade. The whole upgrading process takes less than one minute.
Page 63: Device Restart
Therefore, we recommend that you back up the configuration and save the valid license key before such downgrade. You can make bulk updates for multiple devices via 2N Access Commander. Device Restart To restart the device choose one of the following options: •...
Page 64: Device Control
Door Opening (Switch Activation) by RFID Card 2N IP Style is equipped with a door unlocking switch. To activate this switch, tap a valid card or chip on the integrated card reader. Remember to complete the user access card ID (refer to Subs.
Page 65 Door Opening (Switch Activation) by 2N Mobile Key 2N IP Style is equipped with a door unlocking switch. Activate this switch using the 2N Mobile Key authenti- cation in your smartphone. The application is available for devices with iOS 12 and higher (iPhone 4s and higher) or Android 6.0 Marshmallow and higher (Bluetooth 4.0 Smart supporting phones).
Page 66: Idle Mode
Device Control Idle Mode 2N IP Style switches to the Sleep mode after an idle timeout (default value is 60 s). In the Idle mode, you can go to the Showcase mode to dis- play a presentation or the company logo/address...
Page 67: Rain Test Mode
Device Control Rain Test Mode The Rain test mode shows where water has been detected on the display. When the mode is acti- vated, a black screen is displayed showing the water impact spots. Triple touch quickly any part of the display to delete the impact records. The device does not support the intercom func- tions during the test (no calls, no card reading, etc.).
Page 68: Home Screen
Calls In this state, connection or connection attempt is in progress with another device. The 2N IP Style functions are limited, it is impossible to switch to the home page and go to menus. Possible actions are included in the table below.
Page 69: Outgoing Call
Device Control Outgoing Call Active Call Possible ac- Performance Action result tions Incoming call Connection with the other device has been established, a receiving call is in progress. The call can be ended without answering. End of Call The outgoing call is cancelled./The incoming call is rejec- ted./The active call is interrupted.
Page 70: Directory Menu
Device Control Virtual Number Call If the Calling Virtual Numbers parameter is set (refer to Calls > General Settings of the Configuration Manual for IP Intercoms), you can dial a user-defined phone number using the device numeric keypad. Press the button. Enter the phone number using the numeric keypad and repress the green button for confirmation.
Page 71 Device Control Pictogram Description Means that the area where the device is located is secure. To activate the area security, for example, assign it to a physical input, use HTTP API and so on. Means that the door unlocking switch is activated. Refer to Device Control (p.
Page 72: Maintenance - Cleaning
Maintenance - Cleaning Maintenance - Cleaning 2N IP Style contains no environmentally harmful components. Dispose of the device in accordance with the applicable legal regulations. 2N IP Style contains no environmentally harmful components. Dispose of the device in accordance with the applicable legal regulations.
Page 73: Troubleshooting
Troubleshooting Troubleshooting Refer to faq.2n.com for the most frequently solved problems.
Page 74: Technical Parameters
Technical Parameters Technical Parameters Power Supply Types: IEEE 802.3af (Class 0, max. 12.95 W) External supply 12 V ±15 % / 4 A DC Signaling protocol UDP, TCP, TLS Audio Microphone 2 integrované Amplifier 2 x 4 W (class D) Speaker 2 x 4 W / 4 Ω...
Page 75 Technical Parameters Audio stream Protocols • RTP • RTSP • SRTP Codecs and Used Bandwidth • G.711 (PCMA, PCMU) – 64 kbps (with 85.6 kbps headers) • G.729 – 16 kbps (with 29.6 kbps headers) • G.722 – 64 (with 85.6 kbps headers) •...
Page 76 Technical Parameters Video stream Protocols • RTP • RTSP • SRTP • HTTP ONVIF/RTSP streaming codecs • H.264 • H.265 • MJPEG IP Camera Function Yes – compatible profiles: • ONVIF v2.4 profile S Interface 10/100BASE-TX with Auto-MDIX, RJ-45 Recommended cabling Cat-5e or higher Supported protocols SIP2.0, SIPS, DHCP opt.
Page 77 HID MIFARE DESFire with SIO, HID MIFARE Clas- Maximum magnetic field strength at 10 m: sic with SIO) 1.492e-3 W/m² • Mobile Key • 2N PICard Maximum magnetic field strength at 10 m: 3.747e-4 W/m² Bluetooth Bluetooth in compliance with BLE (Bluetooth Low Energy)
Page 78 Technical Parameters Touch Display Resolution 85 dB (pro 1 kHz ve vzdálenosti 1 m) Contrast ratio 800 : 1 Brightness 85 dB (pro 1 kHz ve vzdálenosti 1 m) Viewing angle 85° from all directions Numeric Keypad numeric touch keypad, Touch buttons press the display Directory...
Page 79 Technical Parameters Mechanical Parameters Cover Hardened glass Body material • Material - EN-AW6060 • Surface finish: body - RAL 7021 (dark grey variant), chas- sis - RAL 7043 Dimensions (w x h x d) 170.6 x 355.5 x 41.8 mm; 170 x 355 x 22 mm (overlapping part of the device when flush-mounted) Weight 1 950 g...
