Delete A Snapshot - IPC IQ/MAX TOUCH User Manual

Figure 28: Rename a snapshot
1. Expand the Navbar to view the snapshot names.
2. Tap the snapshot name to be edited.
3. Tap the
Edit
icon:
Edit
The Edit Snapshot dialog opens.
Figure 29: Edit a snapshot
4. Tap the name in the Edit Snapshot dialog.
5. Edit the name using the soft keyboard. A maximum of 20 characters can be entered.
6. Tap
Rename
The new snapshot name is saved.
Note
The snapshot name cannot be blank and must be unique.
3.10.5

Delete a snapshot

You can delete a snapshot.
1. Expand the Navbar and identify the snapshot to be deleted.
2. Tap the
Edit
The Edit Snapshot dialog opens.
IPC Proprietary
icon next to the selected snapshot name.
.
icon next to the selected snapshot name.
3.10: Snapshots
IQ/MAX TOUCH Turret User Guide
45
Unigy 4.3
