144 10.4: Use the Speakers application
•
Tx/Rx Left When PTT/PTL: Transmits and receives audio through the left handset or a headset
( ).
•
Tx/Rx Right When PTT/PTL: Transmits and receives audio through the right handset or a headset
( ).
4. To change one or more speaker channels or talkback groups to use a different media device, tap the
medai device type you want to assign, then tap the channel(s) or group(s) to be configured, one at a
time.
As you tap each channel or group, you see the media device icon (in the lower portion of the channel
or to the left of the speaker group) change to the media device type being configured.
Note
If you are not currently talking on the channel, the changes are made immediately. If you are already
talking back on the channel, the change will not take effect until after you take the channel out of
talkback mode by releasing the Push-to-Talk or Push-to-Latch action. Then the configuration takes
effect upon the next talkback.
10.4.12

Speaker compact view mode

Speaker compact view mode allows you to reduce the size of speaker channels so that more channels are
visible at one time in the Speakers application.
In compact view mode, the following number of channels are visible at one time, depending on the
application view:
•
Full screen view: 32 speaker channels are visible
•
Half screen view: 16 speaker channels are visible
•
Third screen view: 8 speaker channels are visible
Speaker controls are available in compact view mode but some controls are accessed differently given
the limited space.
The red graphic equalizer that indicates audio activity is displayed above the Press-to-Talk button during
a call.
10.4.12.1 Use speaker compact view mode
Use speaker compact view mode to display more speaker channels than are available in normal mode.
For background information, see
1. To turn on speaker compact view mode, tap the Speaker compact view icon in the Speakers
application header bar. See
The Speakers application is displayed in compact view mode.
August 26, 2019
Speaker compact view mode
Speakers on a hard turret on page 128 for an illustration.
on page 144.
