1.
Within the Speakers application, tap the
The batch setting mode options are displayed at the top left in the Speakers application.
2. Tap
Media Device
All speaker channels and groups assigned to the currently selected media device are highlighted with
a blue background as shown in the following figure:
Figure 64: Speaker Media Device - Tx/Rx HFM setting
3. To view which speaker channels and groups are configured for a media device, tap the media device
button.
The following devices are available:
•
Tx/Rx HFM: Transmits audio through the turret microphone, receives audio through a turret
speaker (
•
Tx Left Rx HFM: Transmits audio through the left handset or a headset microphone, receives
audio through a turret speaker (
•
Tx Right Rx HFM: Transmits audio through the right handset or a headset microphone, receives
audio through a turret speaker (
IPC Proprietary
Batch Settings Mode
.
).
).
).
10.4: Use the Speakers application
icon ( ).
IQ/MAX TOUCH Turret User Guide
143
Unigy 4.3
