44 3.10: Snapshots
3.10.3

Modify a snapshot

You can change the arrangement of applications in a snapshot.
When you save snapshot changes, the turret also saves the current state of each application in the
snapshot. For example, it saves the current Favorites sheet so that the same sheet is displayed when you
redisplay the snapshot.
1. Open the snapshot to be modified by tapping the snapshot icon or snapshot name in the Navbar.
2. Add, remove, or replace an application in the snapshot:
•
Add an application: Drag an application from the Navbar and drop it in the main application area
using the positioning guide.
•
Remove an application: Drag an application header bar and drop it in the
the
Close
•
Replace an application: Drag an application from the Navbar and drop it on an existing
application in the main application area.
3. Expand the Navbar and tap the
icon:
Refresh
The changes to the snapshot are saved.
Note
Directly tapping the snapshot icon or name after modifying the snapshot takes you to the previously
saved arrangement of applications in the snapshot, without saving the current arrangement.
3.10.4

Rename a snapshot

You can rename a saved snapshot.
The snapshot names are displayed only when the Navbar is expanded. When the Navbar is collapsed,
only the snapshot icons are displayed. A snapshot icon displays a two letter name that is derived from
the first letters of the first two words of the snapshot name, considering space as a word separator. The
snapshot icon cannot be edited. You can edit the snapshot name.
August 26, 2019
icon next to the application name in the expanded Navbar.
Refresh
icon next to the snapshot name.
area. Or tap
Close App
