120 9.1: Conferences
Terminology for button status indication:
•
I-Busy: I am busy on a call using a button representing a selected line. A line button representing an
I-Busy line is green.
•
U-Busy: You are busy on a call using a button representing a selected line. This is the status
indication for a line on which someone else is active, or has put a call on exclusive hold. It indicates
the line is in use by another user. A line button representing a U-Busy line is blue.
•
I-Hold: I placed a call on hold using the line represented by the button. A line button representing an
I-Hold line is flashing dark green.
•
U-Hold: You placed a call on hold using the line represented by the button. A line button representing
a U-Hold line is dark blue.
•
Idle: The line is available for use. Note, however, that for speakers the line can show idle even if the
line is in use. This would occur if the line's
enabled. This setting is generally used for private lines.
•
Incoming: An indication that there is an incoming call for the line represented by the button. There is
an option for this display, high priority indication and low priority indication.
Scenario 1: Rules for adding and removing lines in a conference
1. User A makes a call on Line 1.
Result: Line 1 shows I-Busy to User A and U-Busy to all others in the system.
2. User A conferences in Line 2, which creates a conference call.
Result: Line 2 shows I-Busy to User A and U-Busy to all others in the system.
3. User B barges in to Line 1.
Result: Line 1 also now shows I-Busy to User B. Line 2 continues to show U-Busy to User B.
Both User A and User B have the ability to add lines to this conference. User A can remove the lines
that User A has added. User B can remove the lines that User B has added.
Scenario 2: Conference creator puts conference on unsupervised hold, then creator
resumes the conference
1. User A creates a conference with 3 lines on the left handset.
Result: All lines show I-Busy to User A and U-Busy to all others in the system.
2. User A presses hold and an unsupervised conference is created.
Result: All lines show U-Busy to User A and all others in the system.
3. User A resumes conference by pressing left conference or one of the 3 line buttons.
Result: All lines show I-Busy to User A and U-Busy to everyone else.
User A can remove any line from the conference since User A was the unsupervised conference creator.
Scenario 3: Conference creator puts conference on unsupervised hold, then a different
user resumes the conference
1. User A creates a conference with 3 lines on the left handset.
Result: All lines show I-Busy to User A and U-Busy to all others in the system.
2. User A presses hold and an unsupervised conference is created.
August 26, 2019
Display Status When on Speaker
property is not
