Figure 14: Contextual menu
2.4

Footer area

The Footer is located on the bottom of the Primary Module touch screen. The Footer is not available on
the Expansion Module.
The Footer contains the left and right handset status area, the master volume bar, the user name, call
notification area and messaging area (all three in the same location), the user badge, the voice mail
indicator, and the time. The following figure includes three instances of the footer to illustrate that the
same location is being used for three purposes (user name, call notification area, and messaging area).
Figure 15: Footer on Primary Module
1 User name
2 Voice mail indicator
3 Messaging area
4 Left handset status area
5 Right handset status area
6 Master volume bar or slider – controls the volume of speaker channels and calls on hands-free
mode
7 Call notification area
