1 Collapsed Navbar (icons visible only)
2 Expanded Navbar (icons and labels visible)
3 Snapshots group header
4 Snapshot items
5 Save Views button
6 Applications group header
7 Application item with Remove or Close icon (x) – icon is visible when more than one application is
open
8 Application item with Add or Open icon (+) – icon is visible when fewer than three applications
are open on the Primary Module, or fewer than six applications if an Expansion Module is present
9 Navbar handle
The Snapshots group consists of the Snapshots group header, a list of snapshot items (if defined), and
the Save Views button. The Applications group consists of the Application group header and a list of
application items.
Tapping the Snapshots group header icon toggles the snapshot view between viewing individual
snapshot icons and collapsing all snapshots into a single group header icon. The Applications group
header icon works in the same way.
You can open and close applications, and create and load snapshots from the Navbar. When an
application or snapshot is open, its icon is highlighted in the Navbar.
2.3

Application area

The Application area, also called the Main Application area, can display up to three applications
simultaneously. Up to six applications can be displayed when a Primary Module and an Expansion
Module are present.
When only one application is visible, it is displayed at full size or full screen. When two are visible, they
are displayed at half size or half screen. When three are visible, they are displayed at third size or third
screen. The applications are displayed side by side on the screen in equally sized areas.
An application consists of a Header bar, application content, and optionally an open drawer. The Header
bar contains the application icon, the application name, and other icons such as Settings, Filter, and Add.
The icons vary by application. When tapped, some icons open a drawer, while other icons open a dialog.
The application content differs from application to application, and may differ when the application is
running at full size, half size, or third size. Many applications have a scrollbar or scrubber on the right-
hand side of the application content.
