10.3: Speaker channel status messages

•
Speaker solo mode
•
Muted by my handset: muted due to handset access of the line by the end user
•
Muted by other handset: muted due to handset access of the line by another end user
•
Muted by other microphone: muted by another user's microphone (due to global mute microphone of
the line by another user)
Channel states visible on the off-screen speaker activity grid
The following describes the channel states viewed from the off-screen speaker activity grid:
•
Gray plus sign: unassigned
•
Gray number: assigned off
•
Blue number: assigned on
•
Green box: lamped
•
Red number in a red box: muted by other
•
Red number without a box: muted by the user
•
Green number: speaker solo mode
For an illustration of Speakers and the off-screen speaker activity grid, see
page 128.
10.3 Speaker channel status messages
Status messages provide information about the status of a speaker channel. When available, a status
message is displayed on the lower part of a speaker channel.
Status messages on a speaker channel are described next.
CONNECTING – Channel is attempting to connect to a line.
FAIL – Channel failed.
FAILED, RETRYING – Channel could not connect to a line and is retrying.
NO PERMISSION – You do not have permission to listen or speak on this Open Connexion line.
SPEAKER MUTE ON – You have muted the channel.
SPEAKER MUTED – Channel is not in talkback and is muted by the system. Or channel is in talkback,
and you can talk but cannot receive audio.
SPEAKER & MICROPHONE MUTED – Channel is in talkback but you are not allowed to talk back or
receive audio.
TAP TO TURN ON – Channel has been assigned to a line and is currently turned off.
10.4

Use the Speakers application

10.4.1

Turn individual speaker channels on or off

Turn a speaker channel on to initiate a speaker call and turn it off to end a speaker call. A speaker call is
active until the speaker channel is turned off.
Prerequisite: The speaker channel has been assigned to a line, and you have the appropriate licenses and
privileges to access the speaker channel.
August 26, 2019
Speakers on a hard turret on
