30 2.4: Footer area
8 User badge – shows user's presence; allows access to the User menu popover
9 Time
2.4.1

Handset overlay

Tap the left or right handset status area in the Footer to reveal the handset overlay (also called
Contextual Call Display).
The handset overlay, or Contextual Call Display (CCD), shows controls relevant to a new call or an
active call. Some controls for an active call differ depending on the call type. This topic shows some
examples of the controls on a handset overlay, but does not cover all possible types of calls.
The color of the handset overlay indicates the state of the handset:
•
Gray – handset ready
•
Light blue – transition state (for example, setting up a call)
•
Green – active call
Figure 17: Handset overlay (handset ready)
1 Hide button – toggle to hide or show the handset overlay
2 Volume bar (volume slider) – adjust receive volume
3 ICM Hands-Free– toggle intercom hands-free mode on or off
4 Call Swap (inactive) – call swap not available until line call is established
5 Privacy – toggle privacy feature on or off
6 Intercom
7 Intercom Group Call
8 Intercom Group Answer
9 Intercom Group Talkback
When you tap
Intercom
point intercom call, as illustrated in the following figure.
August 26, 2019
on the initial handset overlay, the handset overlay shows controls for a point-to-
