148 10.5: Speaker groups
1. Tap the
Batch Settings Mode
Figure 66: Speakers: Groups
1
Batch Settings Mode
2
Groups
3 Groups the speaker channel is assigned to
4 Currently selected speaker group
2. Tap the
Groups
3. At the bottom of the screen, tap the speaker group to which you are assigning the speaker channels.
4. Tap one or more speaker channels to add them to the group.
The speaker group number is displayed within the speaker channel.
5. Tap the
Batch Settings Mode
For information on setting the latch behavior for the speaker groups, refer to
speaker groups
10.5.2

Remove a speaker channel from a speaker group

You can remove a speaker channel from a speaker group.
1. Tap the
Batch Settings Mode
August 26, 2019
icon.
icon
button
button.
icon to leave edit mode.
on page 149.
icon.
Set the latch type for
IPC Proprietary
