Lucent Technologies SLC-2000 Remote Terminal Assembly Manual page 95

363-208-010
Cabling, Wiring, and Assembly
Test Access Path (TAP) Interface
TAP Bay Cable Assembly ED7C723-34
Group 1
Step 1: Refer to Figures 3-17 and 3-18 connect the TAP Interface cable assem-
bly as follows in the left side cable duct:
Step 2: Position the unused/unassigned connectors so that future access for
additional growth shelves is possible. After the connections have been
made, tie the cable assembly down towards the rear of the left duct.
TAP Connector
P301 to be connected later
J275 P275 ARM Shelf
J301-4 P301 MDS 4
J301-3 P301 MDS 3
J301-2 P301 MDS 2
J301-1 P301 MDS 1
Mating Connector
