Test Head Installation
Step 3: Mate the 955-7000010108 cable's MTAU connector to the MTAU con-
nector of the dangler cable, 955-7000107 or 955-7000xxx035,
installed previously.
Step 4: Mate the 955-7000010108 cable's P44 connector to the J44 connector
of the ARM shelf.
NOTE
If the ARM shelf is mounted in a frame that is backed up against a wall, the
access to J44 will be very difficult. It may be necessary to remove the
mounting screws from the ARM shelf and slide it forward to gain access to
J44. Reattach the ARM shelf to the frame after connecting the test head
cable to J44.
Step 5: Connect the TL1 DB25 connector to the circuit for communications to
special services test operations system, such as, SARTS, as deter-
mined by the customer.
Step 6: Connect the Alarms DB15 connector to the SLC -2000 miscellaneous
alarms as determined by the customer.
Communications Cable
This cable assembly, containing the test access pairs, is connected to the
Miscellaneous Pairs Cross-connect block. See Figure 1-1 for the cabling and
Figure 1-6 for the signals on J14 of the test head.
Step 1: Locate the test head's 955-7000000046 dangler cable and the 955-
70079 or 955-7000xxx036 cable that were installed previously.
Step 2: Mate the 955-70079 or 955-7000xxx036 cable's J301 connector with
the P301 connector of the ED7C723-34, Group 1 TAP bay cable.
Step 3: Locate the test head's two 955-7000xxx126 cables.
Step 4: Mate the first 955-7000xxx126 cable to the MLT Control RJ11 connec-
tor of the 955-70079 or 955-7000xxx036 cable.
Step 5: Mate the second 955-7000xxx126 cable to the Monitor/Talk RJ11 con-
nector of the 955-70079 or 955-7000xxx036 cable.
Step 6: Connect the first 955-7000xxx126 cable MLT Control RJ11 connector
to the POTS VF circuit as determined by the customer.
Step 7: Connect the second 955-7000xxx126 cable Monitor/Talk RJ11 con-
nector to the POTS VF circuit as determined by the customer.
:
