Lucent Technologies SLC-2000 Remote Terminal Assembly Manual page 267

363-208-010 Appendix 2
NE00676-70 Local Alarm Relay Unit Installation Procedure
Step 26: The connections and functions are shown in the following table:
Function
OACRA
OACRV
OAMJA
OAMJV
OAMNA
OAMNV
OAMSA
OAMSV
OANPA
OANPV
Step 27: Procedure complete.
J306/P306 TERMINATIONS
Pin Pin Function
1 14 OACRAR
2 15 OACRVR
3 16 OAMJAR
4 17 OAMJVR
5 18 OAMNAR
6 19 OAMNVR
7 20 OAMSAR POWER MINOR AUDIBLE
8 21 OAMSVR
9 22 OANPAR
10 23 OANPVR
Title
CRITICAL AUDIBLE
CRITICAL VISUAL
MAJOR AUDIBLE
MAJOR VISUAL
MINOR AUDIBLE
MINOR VISUAL
POWER MINOR VISUAL
NO POWER AUDIBLE
NO POWER VISUAL
Issue 1.0 August 1998 9
