363-208-010
Installation Procedures

Mounting System Shelves

NOTE
These procedures shall be followed when separate shelves must be
mounted, when increasing system capacity, or when equipment shelves
must be replaced. Refer to the Figure 2-5 or 2-7 for equipment shelf loca-
tions.
NOTE
RT Frames may have been pre-assembled at an Lucent Technologies Ser-
vice Center with a complement of shelves in accordance with an engi-
neered order or may have only a minimum complement of shelves
equipped. In either case the customer's order should be checked for the
correct configuration of shelves. RT frames coded J1C265A-1 may have
been ordered from the supplier as a complete complement of shelves, fac-
tory mounted and interconnected.
NOTE
Shelves must be assembled only in accordance with the Mounting Hole
Locations in Figure 2-5 or 2-7. To mount the shelves otherwise would
destroy the integrity of the system airflow, the local cable connections and
the growth pattern.
NOTE
Before attaching the shelf's ground wire to the bay frame, remove as much
of the frame's paint as necessary to ensure a low-resistance ground and
apply an oxidation preventative such as NO OX-ID "A".
:
:
:
:
Issue 5 May 1997 2-11
