Ancillary Equipment - Lucent Technologies SLC-2000 Remote Terminal Assembly Manual

363-208-010
Installation Procedures

Ancillary Equipment

The ordering and placement of the following 4TEL RMU
shall be done in accordance with the instructions within the manuals for the
subject equipment. The figures referenced herein convey only suggested
locations within the SLC -2000 bays; and may be restricted because of cable
length limitations.
NOTE
The use of either the 4TEL RMU , LTF, and Reliance INTS or combinations
thereof requires an auxiliary power source outside of the SLC -2000 equip-
ment such as the Reliance Fuse Alarm Panel.
Line Test Fanout (LTF)
If a LTF is required (multiple SLC -2000 systems within one RT), and the RMU is
provided, it shall be installed as indicated in Figure 2-8.
NOTE
The left and right mounting brackets are not part of the LTF and must be
provided separately.
If a LTF is associated with the Reliance INTS only, then it must be mounted on its
own mounting shelf.
4TEL RMU
Mount the RMU or RMU /LTF with the required auxiliary fuse panel within 6 inches
of each other at the top of the equipment bay suggested by Figure 2-9.
Reliance INTS
Mount the Reliance INTS with the required auxiliary fuse panel within 6 inches of
each other at the top of the equipment bay suggested by Figure 2-10.
* 4TEL and RMU are registered trademarks of Teradyne, Inc.
:
:
*
and Reliance OEM items
Issue 5 May 1997 2-21
