Shelf Equipment; Arm Shelf Parts - Lucent Technologies SLC-2000 Remote Terminal Assembly Manual

363-208-010
Parts Description

Shelf Equipment

ARM Shelf Parts

The ARM shelf is provided by the manufacturer with the following individual cable
assemblies and hardware. The following listings can be used as an ordering guide
or as an installation checklist for material previously ordered. The material that is
indicated as optional is required for specific purposes. All pieces are shipped with
the shelf, but some parts (*) may be loosely attached or shipped in separate
containers.
J1C265AA-1 List 1 ARM Shelf Assembly
equipped with
ED7C723-30 Group 1
ED7C723-30 Group 2
ED7C723-30 Group 3
ED7C723-30 Group 4
ED7C723-30 Group 5
ED7C723-30 Group 6
ED7C723-30 Group 7
ED7C723-30 Group 8
ED7C723-30 Group 9()**
ED7C723-30 Group 10()
ED7C723-30 Group 11()
ED7C723-30 Group 12()
(6) 801486341*
(2) 402444491*
(2) 846944411*
(1) 406203182*
(1) 406421032*
(2) 406203190*
** The parenthesis after the group number of the cable
assembly means that there may be an alpha character
after the numeric character, e.g., Group 2 or Group 2A
or Group 2B.
5-2
Issue 5 May 1997
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Cable Assembly
Screws, special round head
Studs, slotted
Labels, system identification
Fuse, 0.5 amp
Fuse, 2.0 amp
Fuses, 10 amp
