363-208-010
Cabling, Wiring, and Assembly
DC Test Pair
Figure 3-52. DC Test Pair J301 Wiring
26
1
30
5
35
10
40
15
45
20
Tip
W/BL
50
25
WIRING SIDE
J301
O/W
INH
BL/W
Ring
DC Test Pair
Issue 5 May 1997
3-95
