Bay Frame Mounting - Lucent Technologies SLC-2000 Remote Terminal Assembly Manual

363-208-010
Installation Procedures

Bay Frame Mounting

Step 1: Move the bay to its proper floor location. Exercise care when moving the
bay, avoiding sudden shock or strain to equipment shelves, if equipped.
Do not handle or support the frame by the side covers.
Step 2: The bay can be erected into position by using two or more people. For
added safety, located at the very top of the bay are three 5/8- by 11 inch
holes. These holes are for lifting. When required, assemble the 5/8- by
11 inch eye bolt into these holes, and tie off with rope temporarily to
some solid structure overhead (refer to Figure 2-3).
Step 3: Lift the bay and place into the proper location in the lineup. Visually
inspect for obvious damage.
Step 4: Before the bay is secured to the floor, verify that it is level so that align-
ment of adjacent bays via junction plates can be achieved.
Step 5: Use the job specification information for positioning the bay frame to its
assigned lineup location.
Step 6: Use Figure 2-2 as a drilling template which specifies the hole locations
in the framework base. Use location 1 first; then location 2 if an obstruc-
tion in the concrete is hit; then 3 and 4, if necessary. The number of drill-
ings is dependent upon the earthquake zones and local building
practices.
Step 7: Follow local practices for securing the frame to the floor otherwise refer
to the detailed information pertaining to floor layout and placement
methods in the SUPPLEMENTARY INFORMATION chapter of this man-
ual.
Step 8: Secure the frame to the overhead superstructure using the furnished
hardware specified in Figure 2-3.
Issue 5 May 1997 2-5
