Cabling, Wiring, and Assembly
TIP
W/BL
W/O
W/GR
W/BR
W/S
R/BL
R/0
R/GR
R/BR
R/S
BK/BL
BK/O
BK/GR
BK/BR
BK/S
Y/BL
Y/O
Y/GR
Y/BR
Y/S
V/BL
V/O
V/GR
V/BR
V/S
Figure 3-39. VF Connections J204 (Channels 76 - 96)
RING
BL/W
26 1
O/W
GR/W
BR/W
S/W
5
30
BL/R
O/R
GR/R
BR/R
S/R
35
10
BL/BK
O/BK
GR/BK
BR/BK
S/BK
40 15
BL/Y
O/Y
GR/Y
BR/Y
S/Y
45 20
BL/V
O/V
GR/V
BR/V
S/V
50 25
WIRING SIDE
J204
Shelf 2, 4, 6, or 8
CP Quad
CH Unit/Ch
Slot
76 73/76 19/4
77 20/1
78
20/2
77/80
79
20/3
80
20/4
81
21/1
82
21/2
81/84
83
21/3
84
21/4
85
22/1
86
22/2
85/88
87
22/3
88 22/4
89
23/1
90 23/2
89/92
91
23/3
92
23/4
93
24/1
94 24/2
93/96
95
24/3
96
24/4
UNASSIGNED
