Cabling, Wiring, and Assembly
COMM T
SAMPLE T
FR GRD
DC TT
Figure 3-56. 4TEL RMU Test Pair Wiring (ED7C723-35, Group 11)
W/G
26 1
W/BR
30 5
NC
BK
35
10
40 15
NC
45 20
W/BL
NC
25
50
WIRING SIDE
J1
G/W
COMM R
BR/W
SAMPLE R
NC
BL/W
DC TR
NC
