Figure 5-23. Atm Performance Monitoring Mode Menu; Table 5-20. Atm Performance Monitoring Mode Menu Options - ADTRAN Quad T1 IMA Installation And Maintenance Practice

TID: TA1248
Unacknowledged Alarms: None
This screen allows you to view the ATM stats for a particular port.
Enter 0 for the network port or 1 - 48 for the customer ports.

Figure 5-23. ATM Performance Monitoring Mode Menu

The ATM Performance Monitoring Mode menu options are shown in

Table 5-20. ATM Performance Monitoring Mode Menu Options

Option Description
1 Change ATM Port Number
2 ATM Performance Data
3 ATM Port Cell Count
Summary
4 Clear All PM for All Ports
61179641AL1-5C
Total Access 1248
ATM Performance Monitoring Mode
Port: Network
1. Change ATM Port Number
2. ATM Performance Data
3. ATM Port Cell Count Summary
4. Clear All PM for All Ports
Selection :
'?' - System Help Screen
Function
This option is used to change the ATM port number
without additional prompting. The current port number
is displayed above the menu items on the ATM
Performance Monitoring Mode menu.
This option displays the
Status Screen" on page 5-40.
This option displays the
Screen" on page 5-42.
This option displays the
Menu" on page 5-43.
Menu Descriptions
Network
Table 5-20.
"ATM Performance Monitoring
"ATM Port Cell Count Summary
"Clear All PM for All Ports
5-39
