61291004L2-5B
TRDDB
®
Digital Data Bank Channel Unit
Installation and Maintenance
Trademarks: Any brand names and product names included in this document are
61291004L2-5, Issue 2
trademarks, registered trademarks, or trade names of their respective holders.
CLEI Code # D4C4EEJB_ _
TRDDB
NO
SX
SYNC
CRC
QM
DISC
REM
NO
DSU
LBK
Figure 1. Total Reach DDB
1. GENERAL
This practice provides installation and maintenance
procedures for the ADTRAN D4 Total Reach
Data Bank (TRDDB) channel unit. Figure 1 is an
illustration of the ADTRAN TRDDB
(P/N 1291004L2).
Revision History
Issue 2 of this document includes an edge connector
pinout illustration.
Features
• 2-wire deployment
• Repeaterless operation
• Bridged tap tolerant
• Span power for remote Total Reach OCU-R
(TROCU-R) termination unit
• Embedded Digital System 6 capabilities for
remote provisioning, configuration, and
performance monitoring
Section 61291004L2-5B
Issue 2, November 2000
1291004
ON
SC
64
56
19.2
9.6
4.8
2.4
QM
LLB
AP
Rx
L
(OUT)
O
G
I
Tx
C
(IN)
DDS
®
Digital
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ADTRAN Total Reach TRDDB
Summary of Contents for ADTRAN Total Reach TRDDB
-
Page 1: Table Of Contents
Normal Mode ........... 6 This practice provides installation and maintenance Figure 9. TROCU-R Remote End Initiated ® procedures for the ADTRAN D4 Total Reach Digital Loopback, Local Loop ......7 Data Bank (TRDDB) channel unit. Figure 1 is an Figure 10. TROCU-R Remote End Initiated illustration of the ADTRAN TRDDB Loopback, Customer Loop ....... -
Page 2: Installation
ADTRAN GPC shelves or D4/SLC-96 channel banks Description (Figure 3). The TRDDB can also be used in The ADTRAN D4 TRDDB is a 2-wire Total Reach applications where an IXC T1 is back-hauled to a DDS functional replacement for the following... -
Page 3: Figure 3. Multipoint Dds Deployment
Signal Pinout (SB) MB The ADTRAN TRDDB plugs directly into a WECO or equivalent D4 channel bank or the ADTRAN ACT 1900/2300 channel bank. No special wiring is required. The 2-wire loop is connected using the Tip (pin 24) and the Ring (pin 51) on the D4 backplane. -
Page 4: Figure 6. Rate Selection And Option Switch
Refer to Table 2 for LED indication. Figure 6. Rate Selection and Option Switch Table 2. LED Indicators False Loopback Immunity ADTRAN’s Protected Loopback family of channel i l a units include an algorithm compatible with SARTS, l a t Hekimian, TPI, and other test systems that virtually eliminates false latching loopback occurrences. -
Page 5: Testing
Cable loss data based on wire type and temperature for the Total Reach DDS Nyquist frequency of 13.3 kHz is listed in Table 4. The ADTRAN TRDDB front panel is equipped with logic level bantam test access jacks that permit testing i t c in both directions using a portable test set. -
Page 6: Figure 7. Trddb Bidirectional Loopback Pass-Thru Mode
TRDDB Bidirectional Loopback Support Table 6. Alternating Loopback Activation The TRDDB will execute a bidirectional loopback Sequence when performing a DS0 loopback at the TRDDB (Figure 7). If the TROCU-R detects a bidirectional loopback during power up synchronization, the i t c TROCU-R allows data to pass on the 4-wire interface i f i by entering pass-thru mode (Figure 7). -
Page 7: Remote Provisioning And Diagnostics
Remote access to provisioning and status information loopback at the TRDDB towards the customer. See is accomplished using ADTRAN Digital System 6 Figure 9. This allows data to be sent from the remote Message protocol, defined in Control and Diagnostic end to test the local loop and the TROCU-R. -
Page 8: Deployment Guidelines
5. DEPLOYMENT GUIDELINES Remote access is accomplished using a defined set of in-band DS0 byte sequences similar to the latching The TRDDB and TROCU-R use technology intended loopback sequence. Commands issued through the to eliminate the need for repeaters and concerns over test system are recognized by the individual channel impairments caused by typical noise and bridged taps. -
Page 9: Maintenance
(800) 827-0807 7. WARRANTY AND CUSTOMER SERVICE ADTRAN Technical Support ADTRAN will replace or repair this product within 10 Presales Applications/Postsales Technical Assistance years from the date of shipment if it does not meet its (888) 726-8663 published specifications or fails while in service (see ADTRAN Carrier Networks Equipment Warranty, Standard hours: Monday-Friday, 7 a.m. - Page 10 61291004L2-5, Issue 2 61291004L2-5B...
