Total Access 1248 Quad T1 IMA 48-Port DSLAM with Modem Installation and Maintenance Practice

Static IP Settings - for IP over ATM Menu

Static IP Settings - for IP over ATM
Main Menu\System Management\Mode Selection and Current IP
The Static IP Settings - for IP over ATM menu (see
all of the IP settings.
TID: TA1248
Unacknowledged Alarms: None

Figure 5-32. Static IP Settings - for IP over ATM Menu

The Static IP Settings - for IP over ATM menu options are shown in

Table 5-32. Static IP Settings - for IP over ATM Menu Options

Option Description
1 IP address
2 Subnet mask
3 VPI/VCI
4 PCR
5-54
Settings\Static IP Settings - for IP over ATM\
Figure
Total Access 1248
Static IP Settings - for IP over ATM
1. IP address
2. Subnet mask
3. VPI/VCI
4. PCR
5. Default Gateway
6. TFTP IP address
7. TL1 Port Number(set >1023) 13001
8. TL1 IP Transport type
9. Reset IP Factory Defaults
MAC Address
Encapsulation is via rfc1483 SNAP
Selection :
'?' - System Help Screen
Function
This option is used to configure the IP address in
decimal dot format (i.e., ###.###.###.###).
This option is used to configure the subnet mask in
decimal dot format.
This option is used to configure the VPI/VCI setting. The
VPI and VCI are used to identify the next destination of a
cell as it passes through a series of ATM switches.
The VPI/VCI must also be provisioned at the upstream
ATM device.
This option is used to configure the Peak Cell Rate
(PCR). The PCR is the maximum number of cells per
second that the ATM can transmit. The PCR default is
3000. Valid values range from 0 to 14488.
5-32) is used to manually provision
192.168.1.1
255.255.255.0
0/32
3000
192.168.1.254
Not Configured
TCP
00-a0-c8-12-6d-f9
Table 5-32.
61179641AL1-5C
