Total Access 1248 Quad T1 IMA 48-Port DSLAM with Modem Installation and Maintenance Practice
Operation Mode for Facility Menu
Operation Mode for Facility
Main Menu\Network Port\IMA Main Menu\IMA Provisioning\IMA Facility Provisioning\IMA All Facilities
Mode for Facility\
The Operation Mode for Facility menu (see
mode for each IMA facility.
TID: TA1248
Unacknowledged Alarms: None
The Operation Mode for Facility menu options are shown in
Table 5-83. Operation Mode for Facility Menu Options
Option
Description
1
IMA_Group
2
Unassigned
3
Pass Thru
5-118
Operation Mode for Facility for # 1 IMA_Group
1. IMA_Group
2. Unassigned
3. Pass Thru
'N' - Next IMA Facility
Selection :
'?' - System Help Screen
Figure 5-81. Operation Mode for Facility Menu
Figure
5-81) provides options for the operation
Total Access 1248
'P' - Previous IMA Facility
Table
Function
This option is used to add a facility to the IMA group.
This option is used to remove a facility from the IMA
group.
This option is only available for facility #1. This option is
used to allow ATM transport over a single facility without
the IMA layer.
Provisioning\Operation
MM/DD/YY
HH:MM
5-83.
61179641AL1-5C
