Total Access 1248 Quad T1 IMA 48-Port DSLAM with Modem Installation and Maintenance Practice
Table 5-67. T1 Performance Monitoring Status Screen Codes (Continued)
Code Definition
CV-P Code Violations
CV-L Code Violations
ES-L Errored Seconds
The T1 Performance Monitoring Status screen hot keys are defined in

Table 5-68. T1 Performance Monitoring Status Screen Hot Keys

Hot Key Description
Backward(2hrs/15min PM)
B
Clear PM Stats
C
Forward(2hrs/15min PM)
F
Next Port
N
Previous Port
P
Select Port
S
5-102
Description
This code indicates an occurrence of either a CRC-6
error or frame bit error on the path.
This code indicates an occurrence of either a CRC-6
error or frame bit error on the line.
This code indicates seconds with either a bipolar
violation or a CRC-6 error on the line.
Function
This hot key is used to display performance monitoring
statistics for the last 2 hours, in 15 minute intervals.
This hot key is used to clear the performance monitoring
statistics.
This hot key is used to display performance monitoring
statistics for the next 2 hours, in 15 minute intervals.
This hot key is used to display the next port.
This hot key is used to display the previous port.
This hot key is used to select a specific port.
Table 5-68.
61179641AL1-5C
