Table 5-100. Edit ADSL Profile Menu Options (Continued)
Option Description
Upstream Options
16 Target SNR
Margin
17 Max SNR
Margin
18 Min SNR
Margin
19 Fast Channel
Max Tx Rate
20 Fast Channel
Min
Tx Rate
21 Interleave
Channel Max
Tx Rate
22 Interleave
Channel Min Tx
Rate
23 Interleave
Channel Max
Delay
61179641AL1-5C
Function
This option indicates the Target
Signal to Noise ratio in dB.
This option indicates the
Maximum Signal to Noise ratio
allowed.
This option indicates the
Minimum Signal to Noise ratio
allowed.
This option is only available
when the Link Type is set to
Fast.
This option is only available
when the Link Type is set to
Fast and the Rate Mode is set to
Rate Adaptive.
This option is only available
when the Link Type is set to
Interleave.
This option is only available
when the Link Type is set to
Interleave and the Rate Mode is
set to Rate Adaptive.
This option is used to set the
maximum delay allowed for the
Interleaving of data. This option
is only available when the Link
Type is set to Interleave.
Settings
0 dB to 15 dB
0 dB to 31 dB
0 dB to 31 dB
ADSL:
32 kbps to 1024 kbps
ADSL2+:
32 kbps to 2048 kbps
ADSL:
32 kbps to 1024 kbps
ADSL2+:
32 kbps to 2048 kbps
ADSL:
32 kbps to 1024 kbps
ADSL2+:
32 kbps to 2048 kbps
ADSL:
32 kbps to 1024 kbps
ADSL2+:
32 kbps to 2048 kbps
1 ms to 63 ms
Menu Descriptions
Default
6 dB
9 dB
0 dB
896 kbps
32 kbps
896 kbps
32 kbps
16 ms
5-143
