Table 5-32. Static IP Settings - for IP over ATM Menu Options (Continued)
Option
Description
5
Default Gateway
6
TFTP IP address
7
TL1 Port Number (set >1023)
8
TL1 IP Transport type
9
Reset IP Factory Defaults
The Media Access Control (MAC) address is set at the factory.
61179641AL1-5C
Function
This option is used to configure the Default Gateway.
The Default Gateway is used to forward traffic to a
destination outside of the subnet of the Total Access
1248. The Default Gateway is configured in decimal dot
format.
This option is used to configure the TFTP IP address.
The TFTP IP Address must be configured to use TFTP for
software upgrade. The TFTP address is configured in
decimal dot format.
This field is used to configure the Transaction Language
1 Port Number. The default TL1 Port Number is 13001,
however, it can be modified to any number greater than
1023.
This option is used to configure the TL1 IP Transport
Type. Each time the TL1 IP Transport type option is
selected, the setting is toggled between User Datagram
Protocol (UDP) and Transmission Control Protocol (TCP).
The default is TCP.
This option displays the
Menu"
on page 5-56.
NOTE
Menu Descriptions
"Restore IP Factory Defaults
5-55
