9. To exit the menu, scroll to and select EXIT, or to adjust another port's audio
level, repeat steps 1 through 8.
Ident tone
The ident tone is disabled in the Easi-PiCo matrix
SYSTEM MENU
EXIT
IP ADDRESS INFORMATION
MAINTENANCE
PASS CODE ENTRY
Figure 1-33: Easi-PiCo System Menu
PASS CODE ENTRY
By selecting the passcode entry screen you can enter the upgrade passcode in to
the matrix to turn your Easi-PiCo matrix in to a full Eclipse PiCo matrix.
The passcode is 16 digits long and is entered using the set up knob; each
character is individually selected by highlighting the character, then pushing the
set up knob activates the character to be changed, and scrolling left and right to
find the specified character, finally pushing the set knob to fix that specific
character. This is repeated until the passcode is entered.
Once the passcode is entered and saved, the display will ask you whether you
would like to "apply the changes".
Select this and the Easi-PiCo will then re-boot and after about 10-20 seconds the
front splash with appear read "ECLIPSE PICO" to confirms the upgrade is
complete.
If the matrix will not let you save or apply the changes, please check the passcode
with your local sales contact or see the contact details in chapter 3 of this user
guide.
AUDIO ROUTES
Read only Screen in Easi-PiCo.
IP ADDRESS
Read only Screen in Easi-PiCo.
SYSTEM INFORMATION
Read only Screen in Easi-PiCo.
SYSTEM STATUS
Read only Screen in Easi-PiCo.
MAINTENANCE SCREEN
Read only Screen in Easi-PiCo; the reboot function is available.
