Note:
Using multiple mobile-phone style headsets in a system could adversely
affect nulling, crosstalk and overall system performance.
Table 1-3: Pin outs for RS-601 Auxiliary Headset Connector
Headset Connector (11)
You connect a headset to the beltpack at the 4-pin male XLR connector labelled
"headset." The headset connector is always active and has priority if a second
headset is connected to the auxiliary ("AUX") connector. You should connect
only one headset at a time to a beltpack.
Table 1-4: Headset Connector Pinout
Pin
Function
Tip
Mic
Ring
Earphone
Sleeve
Common
Pin
Function
1
Mic (Low)
2
Mic (High)
Headphone
3
(Low)
Headphone
4
(High)
E a s i - P i c o U s e r G u i d e
